15
F@ST 1704N
Button on the left panel
LAN x
(1 to 4)
Off No link detected on the Ethernet port
Green steady Ethernet port has detected a link with 100 Mbps device
Green blinking Tx/Rx traffic at 100 Mbps
USB
Off No USB connection
Green steady USB connection available
Green blinking USB connection reading in progress
WPS
Off WPS deactivated
Green steady WPS activated
Green blinking WPS Tx/Rx traffic
Button Meaning
WPS
Active the WPS mode
WLAN
Active the Wi-Fi mode
LED Status Meaning
QIG 253515865 Fast 1704N_EN USA-CA.book Page 15 Vendredi, 21. septembre 2012 10:49 10
