XP Transponders User Guide Rev 1.3
Table 7 – XPG-TR Main Connector Pin Assignments
Pin
Number
Signal
Direction
Signal Char.
Wire Color in Sagetech
Harness p/n XP-CBL-001
(Solid/Band)
Required
1
DC Power
Power
10-32 VDC
White/Tan
Y
2
DC Power
Power
10-32 VDC
White/Brown
Y
3
GND
Power
Gnd
Tan/White
Y
4
GND
Power
Gnd
Brown/White
Y
5
DC Power
Power
10-32 VDC
White/Pink
Y
6
DC Power
Power
10-32 VDC
White/Orange
Y
7
GND
Power
Gnd
Pink/White
Y
8
Com1 RX ADS-B In Data
Input
RS232 Rcv
Orange/White
Optional
9
Com1 TX ADS-B In Data
Output
RS232 Tx
White/Yellow
Optional
10
Com0 TX Command & Control
Output
RS232 Tx
White/Green
Y
11
Not Connected
-
-
-
12
Com0 RX Command & Control
Input
RS232 Rcv
Green/White
Y
13
NO CONNECT
-
-
Y – DO NOT CONNECT
14
NO CONNECT
-
-
Y – DO NOT CONNECT
15
GND
Power
Gnd
White/Violet
Y
16
NO CONNECT
-
-
Y – DO NOT CONNECT
17
GND
Power
Gnd
Violet/White
Y
18
NO CONNECT
-
-
Y – DO NOT CONNECT
19
NO CONNECT
-
-
Y – DO NOT CONNECT
20
Not Connected
-
-
-
21
Not Connected
-
-
-
21
Not Connected
-
-
-
23
Not Connected
-
-
-
24
Not Connected
-
-
-
25
Not Connected
-
-
-
26
Not Connected
-
-
-
