XP Transponders User Guide Rev 1.3
Specifications
XPC-TR
XPS-TR
XPG-TR
XPS-TRB
Serial Communications / General
Operating Altitude
unrestricted
unrestricted
Unrestricted
unrestricted
Transmit Power
250 W nominal
250 W nominal
250 W nominal
250 W nominal
1030 Receive Sensitivity
-73 +/- 4 dBm
-73 +/- 4 dBm
-73 +/- 4dBm
-73 +/- 4 dBm
1090 ADS-B IN Sensitivity
N/A
N/A
N/A
-84 dBm
RF Impedance
Ω
Ω
Ω
Ω
Serial Com0 Control
Proprietary
protocol
RS-232, 57.6 Kb
Proprietary
protocol
RS-232, 57.6 Kb
Proprietary
protocol
RS-232, 57.6 Kb
Proprietary
protocol
RS-232, 57.6 Kb
Serial Com2 GPS Input
N/A
Accord NexNav,
NMEA RS-232, Adj
data rate
N/A
Accord NexNav,
NMEA RS-232,
Adj data rate
Serial Com1 ADS-B In Messages
N/A
N/A
N/A
Proprietary
protocol RS-232,
Adj data rate
Mutual Suppression
Yes
Yes
No
Yes
Altitude Encoder
20,000 – 60,000 ft
20,000 – 60,000 ft
20,000 – 60,000 ft
20,000 – 60,000 ft
ADS-B Out (Extended Squitter)
No
Yes
Yes
Yes
ADS-B In (TIS-B)
No
No
No
Yes
Export Compliance
ECCN 7A994
ECCN 7A994
ECCN 7A994
ECCN 7A994
Power
Supply Voltage
10-32 V
10-32 V
10-32 V
10-32 V
Power Consumption (ON & ALT)
4 watts (typical) 11
watts (max)
7 watts (typical) 12
watts (max)
8 watts (typical) 14
watts (max)
Power Consumption (STBY)
< 1 watt
< 1 watt
< 1 watt
< 1 watt
Certification Plan – TSO and Certification Efforts On-Going
Minimum Operational
RTCA DO-181E,
RTCA DO-260B
RTCA DO-181E,
RTCA DO-260B
Performance Standards
SAE AS8003
SAE AS8003
FAA
TSO-C112e Level
2els, Class 1, TSO-
C166b Class B0,
TSO-C88b
TSO-C112e Level
2els, Class 1,
TSO-C166b Class
A0, TSO-C88b
EASA
ETSO-2C112b,
ETSO-C166a,
ETSO-C88a
ETSO-2C112b,
ETSO-C166a,
ETSO-C88a
FCC
FCC part 87, Part 15
FCC part 87, Part 15
Software
DO-178B level C
DO-178B level C
Complex Hardware
DO-254 level C
DO-254 level C
Environmental Testing
DO-160G
DO-160G
Physical/ Environmental
