7. In the submenu OPERATE MODE – WIRELESS, set LINK. The link process between the
Master and all the Slaves will start.
8. In the submenu OPERATE MODE – CONTROL MODE, set W-DMX or IRC depending on
whether you want to set the master programs from the display or IR remote control.
9. Set Auto modes or static colors that the Master will run. All the Slaves will run the same
program of the Master.
10. The procedure before described, must be done only the first time that the Master / Slave
chain is created. Next times, if the configuration will not have variations, it will need only
to switch on the projectors and they will automatically connect to the Master unit.
11. In order to disconnect at the same time all the Slaves from the Master unit, go in the
submenu OPERATE MODE – WIRELESS of the Master, set UNLINK and press ENTER. After
few seconds all the slaves will be disconnected from the master and their Wireless LED
status indicator will come back white color.
WARNING: this last operation must be done when the chain MASTER/SLAVE is not more used
and not more used for future utilizations. If this operation is not done and you forget which is
the MASTER unit, you are forced to apply the procedure in the previous point 3 in each
projector one by one.
WIRELESS LED status
(Master/Slave) - SLAVE
Green fixed (or yellow fixed in
case of a weaker signal)
Projector linked to a Master. Il Master is ON and it is
transmitting a signal.
Projector linked to a Master, but Master is OFF
WIRELESS LED status
(Master/Slave) - MASTER
Standard transmission of Master signal
Transmission of linking signal (only for few seconds)
6.4 – STAND ALONE WORKING MODE
In stand alone mode, a projector will be able to run static colors or automatic programs,
independently of all the others.
In this mode, in order to avoid accidental pairing with other projectors or transmitters, if the
projector is unlinked (Wireless LED status white), it is useful to set it in IRC mode (OPERATE
MODE – CONTROL MODE – IRC). In this way it will be not able to interact with other units.
If this operation is not done and a unlinked projector is operating in stand alone mode, but in
W-DMX mode (OPERATE MODE – CONTROL MODE – W-DMX), when a link process from an
external unit will start for other projectors and the FLBATPLUS is in the range of this transmitter,
it will link with the transmitter itself and the W-DMX mode will take priority, interrupting the
stand alone mode.
