PARTS LIST
No. Description
Qty.
01
06
07
08
09
10
14
15
17
19
20
22
23
24
25
26
27
28
29
30
31
32
33
35
36
37
38
Cylinde r(left)
Piston
Piston pin
Piston pin retainer
Piston ring
Connecting rod
Cylinder screw set
Crankcase
Rear cover
Breather nipple
Front bearing
Rear bearing
Crankshaft
Pinion (crankshaft)
Pinion gearpin
Collar (crankshaft)
Taper collet & drive flange
Prop washer & nut
Prop nut-spinnet
Prop nut-electric starter
Crankcase screw set
Engine gasket set
Cam gear housing
Cam gear
Cam gear shaft
Steel washer set
Tappet
1
1
1
2
1
1
1 set
1
1
1
1
1
1
1
1
1
1 each
1 set
1 set
1 set
1 set
1 set
1
1
1
1 set
2
No. Description Qty.
39
40
41
42
43
44
45
46
47
48
49
68
69
74
75
77
80
89
821
831
84
85
87
91
93
102
110
151
Pushrod
Pushrod cover & rubber seal
Rocker arm
Rocker arm scraw & nut
Rocker arm pin
Rocker arm bracket (left)
Rocker arm bracke t(right)
Valve (in & out)
Valve spring & keeper & retainer
Valve retainer
Rocket arm cover
Checkvalve (in & out)
Intake manifold
Muffler
Muffler manifold
Muffler gasket
Muffler nut
Idle needle valve
Carburetor complete
Carburetor body assembly
Spray bar assembly
High speed needle valve
Throttle barrel assembly
Carburetor gasket set
Intake veloclty stack
Fuel pump system complete
Anti-loosening nut
Mufflre nut (FA91S,81SGK,100,100GK)
2
2 each
2
2 each
2
1
1
2
2 each
2
2
1 pair
1
1
1
5
2
1
1 set
1 set
1
1 set
1 set
1 set
1 set
1 set
1
1
Figure 9
75
80
151
151
※FA-91S, 91SGK, 100, 100GK
(
91S151
)
TO
Cylinder
TO
Muffler
Fuel Pump System Complete
FA-100/100GK(Main ball bearing)
To Next Page
