Saivod LST1055 - Installation Guide; Selecting an Installation Location; Removing Packaging and Transport Locks; Connecting Water Supply

5 / EN
Washing Machine / User’s Manual
2 Installation
Refer to the nearest Authorised Service Agent for installation
of the product. To make the product ready for use, review
the information in the user manual and make sure that the
electricity, tap water supply and water drainage systems are
appropriatebeforecallingtheAuthorizedServiceAgent.If
theyarenot,callaqualifiedtechnicianandplumbertohave
any necessary arrangements carried out.
C
Preparationofthelocationandelectrical,tapwaterand
waste water installations at the place of installation is
undercustomer'sresponsibility.
Make sure that the water inlet and discharge hoses
aswellasthepowercablearenotfolded,pinchedor
crushed while pushing the product into its place after
installation or cleaning procedures.
B
warning: Installationandelectricalconnectionsof
theproductmustbecarriedoutbytheAuthorized
ServiceAgent.Manufacturershallnotbeheldliablefor
damagesthatmayarisefromprocedurescarriedoutby
unauthorized persons.
A
warning: Priortoinstallation,visuallycheckiftheproduct
hasanydefectsonit.Ifso,donothaveitinstalled.
Damagedproductscauserisksforyoursafety.
2.1 Appropriate installation location
• Placethemachineonarigidfloor.Donotplaceitona
long pile rug or similar surfaces.
• Totalweightofthewashingmachineandthedryer-with
full load- when they are placed on top of each other
reachestoapprox.180kilograms.Placetheproduct
on a solid and flat floor that has sufficient load carrying
capacity!
• Donotplacetheproductonthepowercable.
• Donotinstalltheproductatplaceswheretemperature
mayfallbelow0ºC.
• Placetheproductatleast1cmawayfromtheedgesof
other furniture.
2.2 Removing packaging reinforcement
Tiltthemachinebackwardstoremovethepackaging
reinforcement.Removethepackagingreinforcementby
pullingtheribbon.
2.3 Removing the transportation locks
A
warning: Donotremovethetransportationlocksbefore
taking out the packaging reinforcement.
warning: Removethetransportationsafetyboltsbefore
operatingthewashingmachine!Otherwise,theproduct
willbedamaged.
1.Loosenalltheboltswithasuitablespanneruntilthey
rotate freely
(C).
2.Removetransportationsafetyboltsbyturningthem
gently.
3.AttachtheplasticcoverssuppliedintheUserManualbag
into the holes on the rear panel.
(P)
C
Keepthetransportationsafetyboltsinasafeplaceto
reusewhenthewashingmachineneedstobemoved
again in the future.
Never move the product without the transportation safety
boltsproperlyfixedinplace!
2.4 Connecting water supply
C
Thewatersupplypressurerequiredtoruntheproductis
between1to10bars(0.1–1MPa).Itisnecessaryto
have10–80litersofwaterflowingfromthefullyopen
tap in one minute to have your machine run smoothly.
Attach a pressure reducing valve if water pressure is
higher.
Ifyouaregoingtousethedoublewater-inletproduct
as a single
(cold) water-inlet unit, you must install the
suppliedstoppertothehotwatervalvebeforeoperating
the product. (Applies for the products supplied with a
blindstoppergroup.)
A
warning: Modelswithasinglewaterinletshouldnotbe
connectedtothehotwatertap.Insuchacasethelaundry
will get damaged or the product will switch to protection
mode and will not operate.
warning: Donotuseoldorusedwaterinlethosesonthe
newproduct.Itmaycausestainsonyourlaundry.
1.Connectthespecialhosessuppliedwiththeproductto
thewaterinletsontheproduct.Redhose(left)(max.90
ºC)isforhotwaterinlet,bluehose(right)(max.25ºC)is
for cold water inlet.
A
warning: Ensure that the cold and hot water connections
are made correctly when installing the product.
Otherwise,yourlaundrywillcomeouthotattheendof
the washing process and wear out.
2.Tightenallhosenutsbyhand.Neveruseatoolwhen
tightening the nuts.
