6 / EN
Washing Machine / User’s Manual
3.Openthetapscompletelyaftermakingthehose
connection to check for water leaks at the connection
points.Ifanyleaksoccur,turnoffthetapandremovethe
nut. Retighten the nut carefully after checking the seal. To
preventwaterleakagesanddamagescausedbythem,
keep the taps closed when the machine is not in use.
2.5 Connecting to the drain
• Theendofthedrainhosemustbedirectlyconnectedto
thewastewaterdrainortothewashbasin.
A
warning: Yourhousewillbefloodedifthehosecomes
out of its housing during water discharge. Moreover, there
is risk of scalding due to high washing temperatures!
To prevent such situations and to ensure smooth water
intakeanddischargeofthemachine,fixtheendofthe
discharge hose tightly so that it cannot come out.
• Thehoseshouldbeattachedtoaheightofatleast40
cm, and 100 cm at most.
• Incasethehoseiselevatedafterlayingitonthefloor
levelorclosetotheground(lessthan40cmabovethe
ground),waterdischargebecomesmoredifficultandthe
laundrymaycomeoutexcessivelywet.Therefore,follow
theheightsdescribedinthefigure.
100cm
40cm
• Topreventflowingofdirtywaterbackintothemachine
and to allow for easy discharge, do not immerse the hose
end into the dirty water or do not drive it in the drain more
than15cm.Ifitistoolong,cutitshort.
• Theendofthehoseshouldnotbebent,itshouldnotbe
steppedonandthehosemustnotbepinchedbetween
the drain and the machine.
• Ifthelengthofthehoseistooshort,useitbyadding
anoriginalextensionhose.Lengthofthehosemay
notbelongerthan3.2m.Toavoidwaterleakfailures,
theconnectionbetweentheextensionhoseandthe
drainhoseoftheproductmustbefittedwellwithan
appropriate clamp as not to come off and leak.
2.6 Adjusting the feet
A
warning: Inordertoensurethattheproductoperates
moresilentlyandvibration-free,itmuststandleveland
balancedonitsfeet.Balancethemachinebyadjusting
thefeet.Otherwise,theproductmaymovefromitsplace
andcausecrushingandvibrationproblems.
1.Loosenthelocknutsonthefeetbyhand.
2. Adjust the feet until the product stands level and
balanced.
3.Tightenalllocknutsagainbyhand.
A
warning: Donotuseanytoolstoloosenthelocknuts.
Otherwise,theywillgetdamaged.
2.7 Electrical connection
Connecttheproducttoagroundedoutletprotectedbya16
Afuse.Ourcompanyshallnotbeliableforanydamages
that will arise when the product is used without grounding in
accordance with the local regulations.
• Connectionmustcomplywithnationalregulations.
• Powercableplugmustbewithineasyreachafter
installation.
• Ifthecurrentvalueofthefuseorbreakerinthehouseis
lessthan16Amps,haveaqualifiedelectricianinstalla
16Ampfuse.
• Thevoltagespecifiedinthe"Technicalspecifications"
sectionmustbeequaltoyourmainsvoltage.
• Donotmakeconnectionsviaextensioncablesormulti-
plugs.
B
warning: Damagedpowercablesmustbereplacedby
the Authorized Service Agents.
Transportation of the product
1.Unplugtheproductbeforetransportingit.
2. Remove water drain and water supply connections.
3.Drainallwaterthathasremainedintheproduct.(SEE
5.5)
4.Installtransportationsafetyboltsinthereverseorderof
removalprocedure;(SEE2.3)
C
Never move the product without the transportation safety
boltsproperlyfixedinplace!
A
warning: Packagingmaterialsaredangeroustochildren.
Keeppackagingmaterialsinasafeplaceawayfrom
reach of the children.
