Saivod SAPH98 - Parts Identification

36
Parts Name
Front side(fig.5)
1.Top cover
2.Control pane
3.Side panel
4.Air-outlet
5.Front panel
7.Caster
8.Base plate
(fig.5)
Back Side(fig.6)
6. Rear panel
9. EVA filter
10. Continuous drainage
11. Wrapping post
12. Air vent
13. CON filter
14.Drainage
(fig.6)
Check packing accessories, read user’s manual to get how to use them. (fig.7)
(fig.7)
1.Exhaust Pipe Assembly 2. Remote control 3. Window Sealing Plate Assembly
