2-001
SPECIFICATIONS
1. SPECIFICATION DATA
710
915
585 330
960
500
432
475
560
Model PC800
Weight 99 kg ( 220 lbs. )
Dimensions
Overall length 915 mm ( 36.0 in. )
Overall width 500 mm ( 19.5 in. )
Overall height 960 mm ( 38.0 in. )
Vibrating plate (width × length) 500 mm × 585 mm ( 19.5 in. × 23.0 in. )
Compaction width 500 mm ( 19.5 in. )
Speed
25 to 30 m/min
(
82 to 98 ft/min )
Vibration
performance
Frequency 97.0 Hz
Centrifugal force 16.2 kN ( 3,640 lbs. )
Engine
Name HONDA GX160 Gasoline Engine
Model Air-cooled, 4-cycle, 25° inclined, 1-cylinder
Displacement 0.163 L ( 9.9 cu.in )
Performance
Continuos rated output
2.9 kW ( 3.9 HP )
at 3,600 min
-1
Max. output
–
–
Max. torque
11.0 N·m ( 8.1 lbf·ft )
at 2,500 min
-1
Air cleaner Dry type
Starting system Recoil starter
Power line Transmission V-belt
Vibrating system
Vibrator Eccentric shaft type
Clutch Centrifugal type
