Sakura FASN 080-600 - Installation Clearance; Refrigerant Piping

Installation Clearance
To provide sufcient service clearance and to ensure good air intake and discharge, please refer to the
recommendation as follows:
Refrigerant Piping
Long refrigerant piping will affect the performance of the unit and shorten the lifespan of compressor. In the
worst-case scenario, it will cause the compressor to break down. Special precaution needs to be taken to
make sure that the maximum length of the piping strictly adheres to the recommended maximum pipe
length and elevation in the following tables:
35 20 8
8
8
8
8
8
8
8
8
8
20
20
20
20
20
20
20
20
20
35
35
35
35
35
35
35
35
35
FASN080
FASN100
FASN125
FASN150
FASN200
FASD080
FASD100
F
ASD100 X 4
FASD
100 X 2
FASD
125
FASD
125 X 2
FASD
125 X 4
FASD
150
FASD
150 X 2
FASD
150 X 4
FASN250
FASN300
FASN400
FASN500
FASN600
Model
Maximum
Length (m)
Maximum
Elevation (m)
Maximum
Bends
Min 1500mm
Min 1200mm
Min 500mm
Min 500mm
Min 700mm
Min 700mm
Page 15
Sakura Air-cooled Split Ducted Air Conditioner
