Operator’s manual
Front disc mowers
KDF
- 4 -
CAUTION:
Use of the mower for other purposes than the above mentioned is forbidden.
Different use than the above mentioned will be considered as improper and
may lead to revoking of the warranty. Mower should be used, operated and
repaired only by people familiarised with its detailed specifications and with
safety rules and regulations. Wilful changes of the mower will lead to
revoking of the warranty.
3.1. Technical data
Tab. 2. Specifications KDF
Model
KDF 260 KDF 300 KDF 340 KDF 390
Working width 2,60 m 3,00 m 3,40 m 3,90 m
Number of knives [pcs.]
12 (6x2) 14 (7x2) 16 (8x2) 19 (9x2)
Tractor PTO rpm
1000 rpm
Tractor power required 54 kW
(70 HP)
60 kW
(80 HP)
66 kW
(90 HP)
90 kW
(120 HP)
Working capacity
V = 12 km/h
~ 2,8 ha/h ~ 3,5 ha/h ~ 4 ha/h ~ 4,6 ha/h
Swath width 0,9-1,1 m 1,3-1,5 m 1,3-1,6 m 1,3-1,8 m
Transport length 1,65 m 1,65 m 1,65 m 1,7 m
Transport width 2,60 m 3,0 m 3,4 m 3,90
Working width 3,15 m 3,55 m 3,95 m 4,40 m
Weight 805 kg 940 kg 1020 kg 820 kg
Tine/roller conditioner
shaft rpm
-
Noise level L
101 ± 1 dB
L
112,5 ± 1 dB
L
114 ± 1 dB
Tab. 3. Specifications KDF W
Model
KDF 300W KDF 301W KDF 340 W KDF 341 W
Working width 3,00 m 3,00 m 3,40 m 3,40 m
Number of knives [pcs.]
14 (7x2) 14 (7x2) 16 (8x2) 16 (8x2)
Tractor PTO rpm
1000 rpm
Tractor power required 74 kW
(100 HP)
74 kW
(100 HP)
81 kW
(110 HP)
81 kW
(110 HP)
Working capacity
V = 12 km/h
~ 3,5 ha/h ~ 3,5 ha/h ~ 4 ha/h ~ 4 ha/h
Swath width 1,4-1,7 m 1,4-1,7 m 1,4-1,7 m 1,4-1,7 m
Transport length 1,7 m 1,7 m 1,7 m 1,7 m
Transport width 3,0 m 3,0 m 3,40 m 3,40 m
Working width 3,55 m 3,55 m 4,05 m 4,05 m
Weight 1215 kg 1360 kg - 1475 kg
Tine/roller conditioner
shaft rpm
818 rpm
Noise level L
100,5 ± 1 dB
L
112 ± 1 dB
L
113,5 ± 1 dB
W – Mowers with roller conditioner
