Operating instructions for SAMBO Bevel V1.00-2021.03.22
Reassembly Instructions
Refer to Figure 3 and 4
1. Place the Housing (item no. 1) upside down for internal access.
2. Install the O-Ring (item no. 15) in the Housing (item no. 1).
NOTE: Lubricate all O-Rings before installation.
3. Install the upper Thrust Bearing (item no. 13) in the Housing (item no. 1).
4. Separately, install the Bevel Gear (item no. 3) onto the Drive Sleeve (item no. 6), engaging the Bevel
Gear and Drive Sleeve lugs.
5. Install the assembled Bevel Gear (item no. 3) and Drive Sleeve (item no. 6) into the Housing (item no. 1)
and Thrust Bearing (item no. 13).
6. Install the lower Thrust Bearing (item no. 13) onto the Drive Sleeve (item no. 6).
7. Place the Gasket (item no. 22) onto the Housing (item no. 1).
8. Separately, install the O-Ring (item no. 15) in the Thrust Base (item no. 2).
NOTE: Lubricate all O-Rings before installation.
9. Install the Thrust Base (item no. 2) with O-Ring (item no. 15) onto the Housing (item no. 1) and Drive
Sleeve (item no. 6) using Socket Head Cap Screws (item no. 9).
CAUTION: Care must be taken to ensure that the O-ring located in the Thrust Base is not damaged
during installation.
10. Place the gearbox in the upright position.
11. Install the Stem Cover Adapter (item no. 28) and O-Rings (item no. 26 and item no. 27) on the Housing
(item no. 1).
12. Separately, install the Bearings (item no. 11), Collar (item no. 16), Bearing (item no. 12), and additionally
for V0–V4 only, the Retaining Ring (item no. 29). For V5–V9, install the Bearing Washer (item no. 18)
and Bearing Nut (item no. 17) onto the Bevel Pinion (item no. 4).
13. Install the Bevel Pinion subassembly into the Housing (item no. 1).
14. Replace the Oil Seal (item no. 25) in the Input Flange (item no. 8), if required.
15. Place the Gasket (item no. 21) onto the Housing (item no. 1) and install the Input Flange (item no. 8) or
the Spur Gear Attachment.
CAUTION: For proper backlash of the bevel gear set, ensure supplied gaskets and shims (if appli-
cable) are placed between the Input Flange (or Spur Gear Attachment) and Housing.
NOTE: Ensure binding does not occur between the Bevel Pinion and Bevel Gear.
NOTE: Lubricate all Oil Seals before installation.
9
