● To unlock, press and hold key for 3 seconds again.
12. MICROPHONE / EARPHONE JACK
The unit is equipped with a microphone / Earphone jack located at the right side. You can use an optional earphone
(included) for handsfree function.
13. FLASHLIGHT FUNCTION
To use the flashlight function
● When the flashlight is not illumining, press the Flashlight key once to turn and keep it on.
● When the flashlight is illumining, press the Flashlight key to turn it off.
MENU OPERATIONS
Press Menu key once to firstly enter main channel selection from the main screen, press again for next function selection etc.
The menu operation flow chart is as follows.
Main Screen → Main Channel → CTCSS/CDCSS → GROUP Main Channal(Dual Receiving and Dual Transmiting) →
GROUP CTCSS/CDCSS → VOX → Call Tone →Roger Beep → Key Beep → Main Screen
1. SELECT MAIN CHANNEL
To select the main channel
● Press the key 1 time, Main channel number will flash.
● Press or to select new main channel
● Press the GROUP or PTT key to confirm and revert back to the main screen, or the key to confirm
and continue next function setting.
You have 10 seconds to decide before auto-reverting back to the main screen
2. CTCSS/CODE FUNCTION
This function can help you select your group (38 CTCSS /83 CDCSS codes) of users on the same channel.
Only the users with the same CTCSS/CDCSS code can listen and talk to each other. Please note that selecting
a CTCSS/CDCSS code does not assure total privacy.
● Press the key 2 times, CTCSS/CDCSS code will flash.
