3.6.3 Menu Map for Inverting Mode Screens
Menu Maps for the Operating Mode Screens for the "Inverting" Mode are shown as follows:
• Section 3.6.3.1: Fig 3.2(a) for Models EVO-1212F / 1212F-HW / 1224F / 1224F-HW
(Model No. shown in the screens is EVO-1212F)
• Section 3.6.3.2: Fig 3.2(b) for Models EVO-2212 / 3012 / 2224 / 4024
(Model No. shown in the screens is EVO-3012)
3.6.3.1 Menu Map for Inverting Mode Screens for Models EVO-1212F / 1212F-HW / 1224F / 1224F-HW
NOTES:
1. The 1
st
line of the display screen shows Model No. on the left
and the Operating Mode "Inverting" on the right.
2. The 2
nd
, 3
rd
and the 4
th
lines show various
operating parameters and their values.
3. Use Up ñ and Down ò Keys to navigate to the desired
screen.
Up Key
Down Key
E V O - 1 2 1 2 F I n v e r t i n g
A C o u t p u t : 1 2 0 . 0 V
< 0 . 1 A
6 0 . 0 0 H z
Screen
No. 1
E V O - 1 2 1 2 F I n v e r t i n g
A C o u t p u t : < 1 2 W
< 1 2 V A
P F = 0 . 0 0 0
Screen
No. 2
E V O - 1 2 1 2 F I n v e r t i n g
A C i n p u t 1 2 0 . 0 V
< 0 . 1 0 A
6 0 . 0 0 H z
Screen
No. 3
E V O - 1 2 1 2 F I n v e r t i n g
B a t t e r y : 1 2 . 0 0 V
0 . 0 A
E x t e r n a l
0 . 0 A
Screen
No. 5
E V O - 1 2 1 2 F I n v e r t i n g
B a t t e r y 2 5 . 0 C
H e a t s i n k 2 5 . 0 C
T r a n s f o r m e r
2 5 . 0 C
Screen
No. 6
E V O - 1 2 1 2 F I n v e r t i n g
E V O V e r : x . x x I D = 1
R C V e r : x . x x
2 0 1 7 / 0 4 / 2 1 1 5 :
0 0
Screen
No. 7
ð
ð
ð
ð
ð
ð
ð
ð
ð
ð
E V O - 1 2 1 2 F I n v e r t i n g
A C i n p u t < 1 2 W
< 1 2 V A
P F = 0 . 0 0 0
Screen
No. 4
ð
ð
Fig 3.2(a) Menu Map for Inverting Mode Screens for Models EVO-1212F /
1212F-H / 1224F / 1224F-HW (Model No. Shown is EVO-1212F)
ð
ð
ð
ð
To Next Page
