20 | SAMLEX AMERICA INC.
3.6.4.3 Details of Charging Proles in Charging Mode Screens
Refer to the 2nd Line of the following Charging Mode Screens:
• Fig 3.3(a) under Section 3.6.4.1 for Models EVO-1212F / 1212F-HW / 1224F / 1224F-HW
• Fig 3.3(b) under Section 3.6.4.2 for Models EVO-2212 / 3012 / 2224 / 4024
Details of information related to this line on the screen are shown in Table 3.2.
Table 3.2 Details of Charging Stages & Proles Indicated in 2nd Line of Charging Mode Screens
2nd Line of Screens
in Fig 3.3(a) & 3.3(b)
Description
0- Bulk Stage Constant Current, Bulk Stage. [Parameter "CHARGING PROFILE" option: "0 = 3 Stage Adaptive"]
1- Bulk Stage Constant Current, Bulk Stage. [Parameter "CHARGING PROFILE" option: "1 = 3 Stage Type 1"]
2- Bulk Stage Constant Current, Bulk Stage. [Parameter "CHARGING PROFILE" option: "2 = 3 Stage Type 2"]
3- Bulk Stage Constant Current, Bulk Stage. [Parameter "CHARGING PROFILE" option: "3 = 2 Stage Type 1"]
4- Bulk Stage Constant Current, Bulk Stage. [Parameter "CHARGING PROFILE" option: "4 = 2 Stage Type 2"]
5- Bulk Stage Constant Current, Bulk Stage. [Parameter "CHARGING PROFILE" option: "5 = 2 Stage Type 3"]
E- Bulk Stage Constant Current, Bulk Stage. [Parameter "EQUALIZE-4STAGES" option: "1=Yes"]
0- Absorption Stage Constant Voltage, Absorption Stage. [Parameter "CHARGING PROFILE" option: "0 = 3 Stage Adaptive"]
1- Absorption Stage Constant Voltage, Absorption Stage. [Parameter "CHARGING PROFILE" option: "1= 3 Stage Type 1"]
2- Absorption Stage Constant Voltage, Absorption Stage. [Parameter "CHARGING PROFILE" option: "2 = 3 Stage Type 2"]
3- Absorption Stage Constant Voltage, Absorption Stage. [Parameter "CHARGING PROFILE" option: "3= 2 Stage Type 1"]
4- Absorption Stage Constant Voltage, Absorption Stage. [Parameter "CHARGING PROFILE" option: "4= 2 Stage Type 2"]
5- Absorption Stage Constant Voltage, Absorption Stage. [Parameter "CHARGING PROFILE" option: "5= 2 Stage Type 3"]
E- Absorption Stage Constant Voltage, Absorption Stage. [Parameter "EQUALIZE-4STAGES" option: "1=Yes"]
E- Equalization Stage Constant Voltage, Equalization Stage. [Parameter "EQUALIZE-4STAGES" option: "1=Yes"]
0-Float Stage Float Stage. [Parameter "CHARGING PROFILE" option: "0 = 3 Stage Adaptive"]
1- Float Stage Float Stage. [Parameter "CHARGING PROFILE" option: "1= 3 Stage Type 1"]
2- Float Stage Float Stage. [Parameter "CHARGING PROFILE" option: "2 = 3 Stage Type 2"]
3- Charger Off Charger Off, AC Bypass. [Parameter "CHARGING PROFILE" option: "3= 2 Stage Type 1"]
5- Charger Off Charger Off, AC Bypass. [Parameter "CHARGING PROFILE" option: "5= 2 Stage Type 3"]
Charger Off by BMS Charger Off by BMS. [Parameter "BATTERY TYPE" option: "1= Lithium"]
Inverter Stop by BMS Inverter Stop by BMS. [Parameter "BATTERY TYPE" option: "1= Lithium"]
Inverter Off Charger only, Inverter Off. [Parameter "MODE" option: "2= Charger Only"]
SECTION 3 | Operation
