3.6.6 Menu Maps for On-Line Mode Screens
Menu Maps for the On-Line Mode Screens will be similar to the following Menu Map Screens for the default Off-Line
Mode except for some changes explained below:
Mode
Menu Map Screens for Models
EVO-1212F / 1212F-HW / 1224F / 1224F-HW
Menu Map Screens for Models
EVO-2212 / 3012 / 2224 / 4024
Standby Mode Fig 3.1(a), Section 3.6.2.1 Fig 3.1(b), Section 3.6.2.2
Inverting Mode Fig 3.2(a), Section 3.6.3.1 Fig 3.2(b), Section 3.6.3.2
Charging Mode Fig 3.3(a), Section 3.6.4.1 Fig 3.3(b), Section 3.6.4.2
Power Save Mode Fig 3.4(a), Section 3.6.5.1 Fig 3.4(b), Section 3.6.5.2
In the On-Line Mode Screens, the top right of the 1st line displaying the "Operating Mode"will switch every 2 sec
between the "Operating Mode" and "Online" as shown in Fig 3.5(a) to (d) below:
E V O - 1 2 1 2 F S t a n d b y
A C o u t p u t : 0 . 0 V
< 0 . 1 0 A
0 0 . 0 0 H z
E V O - 1 2 1 2 F I n v e r t i n g
A C o u t p u t : 1 2 0 . 0 V
< 0 . 1 0 A
6 0 . 0 0 H z
These 2 screens will switch every 2 sec These 2 screens will switch every 2 sec
E V O - 1 2 1 2 F O n l i n e
A C o u t p u t : 0 . 0 V
< 0 . 1 0 A
0 0 . 0 0 H z
E V O - 1 2 1 2 F O n l i n e
A C o u t p u t : 1 2 0 . 0 V
< 0 . 1 0 A
6 0 . 0 0 H z
Fig 3.5(a) Example of Screen No. 1
of Online / Standby Mode
Menu Map Screens
Fig 3.5(b) Example of Screen No. 1
of Online / Inverting Mode
Menu Map Screens
E V O - 1 2 1 2 F C h a r g i n g
0 - B u l k S t a g e
B a t t : 1 2 . 0 0 V 0 . 0 A
E x t e r n a l :
0 . 0 A
E V O - 1 2 1 2 F P o w e r S a v e
A C o u t p u t : 1 2 0 . 0 V
< 0 . 1 0 A
6 0 . 0 0 H z
These 2 screens will switch every 2 sec These 2 screens will switch every 2 sec
E V O - 1 2 1 2 F O n l i n e
0 - B u l k S t a g e
B a t t : 1 2 . 0 0 V 0 . 0 A
E x t e r n a l :
0 . 0 A
E V O - 1 2 1 2 F O n l i n e
A C o u t p u t : 1 2 0 . 0 V
< 0 . 1 0 A
6 0 . 0 0 H z
Fig 3.5(c) Example of Screen No. 1
of Online / Charging Mode
Menu Map Screens
Fig 3.5(d) Example of Screen No. 1
of Online / Power Save
Menu Map Screens
