SECTION 4 | Parameter Setup
4.4.2.4 FLOAT VOLTAGE (Table 4.3, Screen No. 4)
This sets the charging voltage in the Constant Voltage Float Stage.
4.4.2.4.1 Programming Steps for Parameter "FLOAT VOLTAGE"
ð ð
E V O - 1 2 1 2 F I n v e r t i n g
A C o u t p u t : 1 2 0 . 0 V
< 0 . 1 0 A
6 0 . 0 0 H z
Enter Key Enter Key
Any Operating Mode Screen from
Fig 3.1 to 3.5
[Above screen is Screen 1 of Fig 3.2(a)]
Password 8052
See Section 4.3.1
See Table 4.3, Parameter Setup
Screen No. 4 for
programmable range
S e l e c t G r o u p
* C H A R G E C U R V E
ð
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* B U L K C U R R E N T
2 0 A
ð
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* F L O A T V O L T A G E
1 3 . 5 0 V
S e l e c t P a r a m e t e r
C H A R G E C U R V E
* F L O A T V O L T A G E
1 3 . 5 0 V
Enter Key
Down Key x 3 times
P a s s w o r d k e y i n
0 0 0 0
ð
Enter Key
4.4.2.5 COMPENSATE (Table 4.3, Screen No. 5)
This parameter sets the temperature compensation for the battery. The operational range of the EVO™ Inverter/Charger
is -20°C to 60°C.
This compensation voltage will affect the Absorption Voltage/Equalize Voltage/Floating Voltage/Batt Over Volt/Restart
Voltage/Low Volt Alarm/Batt Low Voltage when the Temperature Sensor is installed on the battery (see Fig 2.5 in the
Owner's Manual for Evolution™ Series Inverter/Charger).
!
CAUTIONS!
1. Lithium Ion charging does not require temperature compensation. Hence, do not use EVO-BCTS
Temperature Sensor when charging Lithium Ion Batteries.
2. Automatic temperature compensation using EVO-BCTS Temperature Sensor is designed for Lead
Acid Batteries based on programming parameter "COMPENSATE". When charging Nickel-Zinc
(Ni-Zn) batteries, ensure that the value of programming parameter "COMPENSATE" is set based
on approximate linear compensation for the particular Ni-Zn battery.
!
ATTENTIONS!
1. Le chargement au lithium-ion ne nécessite pas de compensation de température. Par
conséquent, n'utilisez pas le capteur de température EVO-BCTS lors du chargement de batteries
au lithium-ion.
2. Compensation automatique de la température à l'aide d'EVO-BCTS Capteur de température
est conçu pour les batteries au plomb basée sur la programmation paramètre "COMPENSATE".
Lorsque la charge des batteries Nickel-Zinc (Ni - Zn), s'assurer que la valeur du paramètre de
programmation "COMPENSATE" est déterminé en fonction du linéaire approximatif pour
l'indemnisation de la batterie Ni - Zn particulier.
