Samlexpower PST-600-12 User Manual (English)

Questions and Answers:

J
james33Jul 26, 2025
What to do if Samlexpower Inverter AC output shuts down and the Overload LED is lit?
- C
  Christopher VegaJul 26, 2025
  If the Samlexpower Inverter's AC output shuts down completely, the red "Overload" LED is lit, the buzzer is on, but the green "Power ON" LED and GFCI light are off, it indicates a continuous overload beyond the inverter's power rating. Reduce the load or use an inverter with a higher power rating. If the issue persists after resetting and removing the load, the unit may be defective and you should contact technical support. To reset the unit, switch it off, wait three minutes, and then switch it back on, ensuring the cause of the shutdown is removed beforehand.
P
Philip WardJul 30, 2025
Why Samlexpower PST-600-12 has no AC output and the Over temperature LED is on?
- J
  Julia LeeJul 30, 2025
  If your Samlexpower Inverter has no AC output, the green "Power ON" LED is lit, the buzzer is sounding, and the red "Over temperature" LED is lit, but the green GFCI light is off, it means the unit shut down due to over temperature. This can happen because of fan failure, high ambient temperature, or insufficient air exchange. Check if the fan is working; if not, the fan control circuit may be defective, and you should contact Technical Support. If the fan is working, make sure the ventilation slots are not blocked and that enough cool air is available, and that the ambient air temperature is below 40ºC. Reduce the load to decrease heating. The unit will automatically reset once it cools down.
R
rebeccataylorAug 4, 2025
What to do if Samlexpower Inverter has no AC output and the GFCI is off?
- A
  Aaron MosesAug 4, 2025
  If the Samlexpower Inverter has no AC output, the green "Power ON" LED is lit, but the green GFCI light is off and there is no buzzer alarm, it indicates that the GFCI has tripped. This can occur due to leakage or a Neutral to Ground bond on the load side. You should check the load side circuits for leakage or Neutral to Ground bonding and correct any issues. Then, press the "Reset Button" on the GFCI to reset it, making sure the inverter is ON before resetting.
H
Hannah PowellAug 7, 2025
Why Samlexpower PST-600-12 has no AC output, buzzer is on, but the Power ON LED is lit?
- S
  Savannah PriceAug 7, 2025
  If the Samlexpower Inverter has no AC output, the green "Power ON" LED is lit, the buzzer is on, and the green indication light on the GFCI is off, it means the unit has shut down due to high input DC voltage (exceeding 16.5V for 12V versions or 33V for 24V versions). Verify that the voltage at the DC input terminals is less than 16.5V for 12V versions or less than 33V for 24V versions. Ensure that the maximum charging voltage of the battery charger, alternator, or solar charge controller is below these limits. Also, avoid using an unregulated solar panel to charge the battery, as its output may exceed these voltage limits, especially in cold temperatures. Use a charge controller between the solar panel and the battery.
J
Judy CunninghamAug 16, 2025
Why Samlexpower PST-600-12 buzzer sounds when load is on, but the Power ON LED is lit?
- A
  angel17Aug 16, 2025
  If the buzzer alarm sounds when the load is switched on, and the voltage at the DC input terminals reads between 10 to 10.5V for 12V versions or 20 to 21.0V for 24V versions, while the green "Power ON" LED is lit, the GFCI light is green, and AC output voltage is available, it indicates that the DC input voltage is too low (less than 10.5V for 12V versions or less than 21.0V for 24V versions). To resolve this, ensure the battery is fully charged and recharge it if necessary. Check that the battery cables are thick enough to handle the required current and replace them with thicker cables if needed. Also, tighten all connections in the battery input circuit.
J
Joy PerryAug 20, 2025
Why Samlexpower Inverter has low AC output voltage?
- W
  wfosterAug 20, 2025
  A low AC output voltage (without a buzzer alarm) on your Samlexpower Inverter can be caused by low input voltage at the inverter terminals, especially when the load is near the maximum allowable power. Check that the battery is fully charged and recharge it if it's low. Ensure the battery cables are thick enough to carry the necessary current; use thicker cables if needed. Tighten the connections of the battery input circuit and reduce the load.

Samlexpower PST-600-12 Specifications

General

Brand	Samlexpower
Model	PST-600-12
Category	Inverter
Language	English

Summary

Safety Instructions

General Safety Instructions

Installation compliance, shock prevention, and environment requirements.

Fire and Explosion Hazards

Precautions when working near flammable materials.

Battery Precautions

Handling corrosive electrolyte and hazardous gases.

Inverter Safety Guidelines

Paralleling AC output, DC over-voltage, and reverse polarity.

General Information

Electrical Concepts and Definitions

Voltage, current, power, impedance, and other electrical terms.

Load Types and Characteristics

Classification of loads like linear, non-linear, and resistive.

Output Waveform Comparison

Comparison between Pure Sine Wave and Modified Sine Wave.

Pure Sine Wave Advantages

Benefits of using a pure sine wave output for devices.

Inverter Sizing Factors

Table for matching inverter capacity to load requirements.

Powering SMPS

Understanding SMPS Inrush Current

Explains the inrush current behavior of Switch Mode Power Supplies.

Sizing Inverters for SMPS Loads

Recommendations for selecting inverters compatible with SMPS.

Principle of Operation

Pure Sine Waveform Characteristics

Details of the output waveform including voltage and frequency.

DC to AC Conversion Process

Explanation of the two stages in voltage conversion.

Layout

Front Panel Layout and Controls

Description of the power switch, LEDs, and remote jack.

Rear Panel Layout and Terminals

Details of DC input, AC outlets, and grounding terminals.

Component Identification Legend

Explanation of all panel elements and indicators.

Battery Information for Inverters

Battery Types and Applications

Discussion of deep cycle lead-acid batteries for inverters.

Battery Capacity Ratings

Explanation of Ampere-hour and Reserve Capacity.

Discharge Rates and Voltage Effects

C-Rates, Peukert effect, and voltage drop during discharge.

Battery Bank Sizing and Connections

Calculations for series, parallel, and bank sizing.

Installation

Installation Location Requirements

Environmental and safety considerations for placement.

Mounting Orientation Guidelines

Proper placement for safety and optimal performance.

DC Input Connections and Safety

Guidelines for voltage limits and polarity.

Wire and External Fuse Sizing

Selecting appropriate conductors and fuses for DC connections.

AC Output Connections and Safety

Using GFCI, transfer switches, and grounding for AC output.

Grounding Procedures

Methods for connecting to earth or chassis ground.

Operation

Powering On and Connecting Loads

Recommended sequence for safe operation startup.

Inverter ON/OFF Control Methods

Using front panel switch and optional remote control.

Understanding Idle Current Draw

Power consumption when the inverter is on but not supplying load.

Protections

Overload and Short Circuit Shutdown

How the inverter protects itself from overloads and short circuits.

Low DC Input Voltage Protection

Alarms and shutdown thresholds for low DC input voltage.

High DC Input Voltage Protection

Inverter response to excessive DC input voltage.

Over-Temperature Shutdown

Fan operation and thermal protection mechanisms.

DC Reverse Polarity Protection

Consequences of incorrect DC input connections.

Troubleshooting Guide

Power and Output Issues

Diagnosing problems like no power, no AC output, or low AC voltage.

Alarm and Shutdown Issues

Resolving buzzer alarms, voltage shutdowns, overload, and over-temperature.

GFCI Tripping

Identifying causes and performing resolution for GFCI trips.

Specifications

PST-600 Series Technical Specs

Output, input, and protection details for PST-600 models.

PST-1000 Series Technical Specs

Output, input, and protection details for PST-1000 models.

Environmental and Compliance Data

Operating conditions, certifications, and safety standards.

Warranty Information

Limited Warranty Terms and Conditions

Details on warranty duration, coverage, and exclusions.
