CONNECTING TO A POWER SOURCE
EXTERNAL FUSE AND DC CABLE SELECTION
WATT FUSE CABLE AWG MAX. CABLE LENGTH
1000W 150A #4 1.2m
1500W 200A #2 1.2m
2000W 300A 2 X #2 1.2m
3000W 450A 2 X #2 1.0m
1. Check to be sure the inverter’s power switch is turned off and that no flammable fumes are
present.
2. Identify the positive (+) and negative (-) DC power source (battery) terminals.
3. Install a fuse holder or breaker close to the positive (+) terminal of the DC source (battery).
4. Connect a length of wire on one side of the fuse holder or circuit breaker. Connect the
other end if the wire to the positive (+) terminal of the inverter.
5. Connect a length of wire between the inverter’s negative (-) terminal and the DC power
source negative (-) terminal.
6. Connect a short length of wire to the other terminal of the fuse holder or circuit breaker.
Mark it “POSITIVE” or “+”.
7. Connect the free end of the fuse or breaker wire to the positive terminal of the DC power
source (battery).
8. Insert a suitable fuse in the fuse holder.
9. Check to be sure that all connections between battery clips, terminals and fuse are secure
and tight
.
10. Test the inverter by turning it on and plugging in a 100 watt lamp or equipment.
11. If the inverter is not properly operating, then refer to the troubleshooting sections of this
manual.
CAUTION: Loose connectors may cause overheated wires and melted insulation.
7
