Samson Auro D1200 - Conexiones

Conexiones
Sleeve (ground) Sleeve (ground)Sleeve (ground)
Tip (signal) Tip (signal)
Signal
Unbalanced ¼” Connector to RCA
Ground
Ground
Ground
Ground
Sleeve (ground)Sleeve (ground)
Tip (signal) Tip (signal)SignalSignalSignalSignal
Unbalanced ¼” Connector
GroundGroundGroundGround
Sleeve (ground)Sleeve (ring)Sleeve (ground)
Ring (signal) Signal (tip)
Signal (ring)Tip (signal)
Sleeve (ring)
Signal (tip) Signal (tip)
Signal (tip) Ring (signal)
Tip (signal)Signal (ring)
Balanced TRS ¼” Connector
Solder PointsEnd View
Sleeve (ground)
Cold (3)
Cold (3)
Hot (2)
Common (1)
Male XLR
Signal
Ground
Sleeve (ground)
Signal (tip) Ring (signal)
Tip (signal)Signal (ring)
XLR to Balanced ¼”
Cold (3)Cold (3)
Hot (2) Hot (2)
Common (1)
Male XLR Female XLR
Cold
Solder PointsSolder Points End ViewEnd View
Cold
Hot Hot
CommonCommon Common (1)
XLR to XLR Balanced
El Auro D1200 dispone de entradas y salidas balanceadas con conectores XLR y de
¼" estándar. Siempre que sea posible, use conexiones balanceadas de alta calidad
para evitar posibles interferencias con el resto de equipos. Consulte el diagrama de
cableado siguiente en lo relativo a los conectores del Auro D1200.
72
