Owner’s Manual 3
1. Capsule – Dual, 1-inch (25mm)
diaphragms
2. Pattern Switch – Select from one
of the three pick-up patterns:
Omnidirectional, Cardioid, Figure-8
3. Recording Select Switch – The slide
switch allows you to select the
different recording modes:
Mono: Microphone input and
instrument input are mixed
together and sent to the computer
as a mono signal.
2-Track: Microphone input and
intsrument input are sent to the
computer on separate tracks.
4. Status Indicator – The three color
Power/Clip/Mute LED lights green
to indicate power, flashes red when
the input signal is clipping, and
lights amber when the microphone
is muted.
5. Mute Button – Mutes the output of
the microphone to the computer
and headphone output. The Status
Indicator will illuminate amber
when the microphone is muted.
6. MIC – Control to adjust the
sensitivity of the internal
microphone.
7. INSTRUMENT – Control to adjust
the input level of the instrument
input.
8. VOLUME – Control to adjust
the overall volume of the 1/8”
Headphone output.
9. USB Jack – B size USB connector
for interfacing with your PC or Mac
computer.
1
2
5
7
6
8
3
4
9
G-Track Pro Callouts
