Appendix A: Impedance vs. Expected Power
(NOTE: Measurements taken at 1 kHz, Solid State in, and at 3 kHz, Tube in, with
20 Hz - 30 kHz bandpass filter, to give less than 1% THD)
Model Speaker Impedance Expected Power
5000 4 ohms 2 x 250 W
5000 8 ohms 2 x 170 W
5000 16 ohms 2 x 100 W
7000 4 ohms 2 x 350 W
7000 8 ohms 2 x 240 W
7000 16 ohms 2 x 145 W
