Samson MPL 1640 User Manual

31
Specifications
Maximum Input Level (±3 dB)
Ch Input Mic +14 dB
Ch Input Line +24 dB
Channel fader range +15 dB to -80 dB
Aux send gain range +10 dB to -75 dB
Input Channel Equalization (± 2 dB)
High (10 kHz) ± 15 dB
Mid (800 Hz) ± 12 dB
Low (80 Hz) ± 15 dB
Dimensions (W x D x H) 482 x 373 x 112 mm
19 x 14.7 x 4.4 in
Weight 7 kg • 15.4 lbs
Power Requirements 120 VAC 60 Hz 230/240 VAC 50/60 Hz
Power Consumption 42 w 42 w

Samson MPL 1640 Specifications

General

Brand	Samson
Model	MPL 1640
Category	Mixer
Language	English
