RS110A RS112A RS115A
Output Power
300 Watts Peak
(260 LF + 40 HF)
400 Watts Peak
(300 LF + 100 HF)
170 Watts RMS
(140 LF + 30 HF)
200 Watts RMS
(150 LF + 50 HF)
Max. SPL (1M) 102dB 115dB 116dB
Frequency
Response
60Hz – 20kHz 55Hz – 20KHz 50Hz – 20kHz
Low Frequency
10” (254mm) Woofer
2” (50.8mm) Voice Coil
12” (305mm) Woofer
2” (50.8mm) Voice Coil
15” (381mm) Woofer
2.5” (63.5mm) Voice Coil
High Frequency
1” (25.4mm)
1” (25.4mm) Voice Coil
Crossover
Frequency: 3.5kHz
Type: 24dB/Oct
Frequency: 3kHz
Type: 18dB/Oct
Horn Coverage 84°H x 56°V 90°H x 60°V
Inputs Balanced XLR–1/4” Combo, USB XPD Wireless
Output Balanced XLR Line Output
Contour
Equalization
100Hz & 12kHz Boost
Electronic
Protection
Thermal, Overload, Analog (Optical) Limiter, Compressor
AC Connector
3-pin IEC 250 VAC,
10 A male
3-pin IEC 250 VAC,
20 A male
Power
Consumption
420W
Fuse
110V-120V T5A AC250V;
220V-240V T2.5A AC250V
T: denotes time lag
L: denotes low breaking
capacity
100-120V T6.3AL AC250V;
220-240V T3.15AL AC250V
T: denotes time lag
L: denotes low breaking capacity
Enclosure Polypropylene
Grille Full metal perforated
Handles Two side, one top
Monitor Angle 45°
Mounting
Method
1-38” (35mm) Pole Mount Receptacle, 4 M10 Flypoints
Dimensions
(LxWxH)
12.6” x 11.2” x 22.1”
320 x 285 x 561mm
15” x 12.9” x 23.9”
380 x 327 x 606.5mm
15.2” x 14” x 24.9”
386 x 356 x 631.5mm
Weight 21.6lb / 9.8kg 30.8lb / 14kg 32.6lb / 14.8kg
At Samson, we are continually improving our products, therefore specifications and images are
subject to change without notice.
Specifications
11RS Active Loudspeakers with Bluetooth
®
