Samson SASM4 User Manual

SM4 4-Channel Mixer 11
Specifications
Frequency Response (Level@Max, unity gain +1/-3dB)
Mic to Main 30Hz~30KHz
T.H.D (Level@Max, unity gain, 20Hz~30KHz A-Weighted)
Mic/Line to Main <0.02%
Line to Main <0.02%
Equivalent Input Noise
Mic (Level@Max) <-75dB 20Hz~30KHz A-weighted
Maximum Voltage Gain
Mic to Main 32dB
Line to Main 8dB (RCA Input)
Stereo Line to Main 8dB (1/4’,1/8’ Input)
Residual Noise (30kHz LPF, all control Min)
Main (All Level min) -110dB
Crosstalk (@1kHz w/30kHz LPF)
Input vs. Output (unity gain,Level set min,) >82dB
Input vs. Output (Max output,Level set min) >70dB
Maximum Input Level (@1kHz)
Mic Input -18dB
Maximum Output Level (@1kHz)
Mic Output +14dB
Input Channel Equalizer (±3dB)
High ±12dB@12KHz
Low ±10dB@80Hz
USB Output Power USB3.0 +5V DC 0.2A max
Phantom Power 15 Volts DC
Power Requirements DC15V 800mA
Bluetooth Bluetooth V4.0, A2DP
Dimensions and Weight
Dimensions 8.78” x 5.43” x 1.69”
223mm x 138mm x 43mm
Weight 1.76 lbs / 0.8 kg

Samson SASM4 Specifications

General

Brand	Samson
Model	SASM4
Category	Mixer
Language	English
