User’s Manual
Specifications
General
General
Model Name SAMSUNG 150S
LCD Panel
Size 15.0 inch diagonal
Display area 304.1 (H) x 228.1 (V)
Pixel Pitch 0.297 (H) x 0.297 (V)
Type a-si TFT active matrix
Viewing Angle 70/70/60/60(L/R/U/D), Typical
Synchronization
Horizontal 30 ~ 60 kHz
Vertical 56 ~ 75 Hz
Display Color
16,194,277 Colors
Resolution
Optimum resolution 1024 x 768@60Hz
Maximum resolution 1024 x 768@75Hz
Input Signal, Terminated
RGB Analog 0.7 Vpp positive at 75 ohms
Separate H/V sync, TTL level positive or negative
Maximum Pixel Clock
80 MHz
Power Supply
AC 90 ~ 264 VAC rms, 60/50 Hz ± 3Hz
Signal Cable
15pin-to-15pin D-sub cable, detachable
