5 Exploded View & Parts List
5-2
5-2 LDP21WS Parts List
Location.No
CODE-NO SPECIFICATION & DESCRIPTION Q'TY REMARK
T0003 BN96-03194B ASSY COVER P-FRONT;LS21DP,ABS HB GR70,SV 1 S.A
M0001 BN90-00898A ASSY COVER FRONT;LS21DPWASQ/EDC 1 S.N.A
T0022 BN64-00479B KNOB CONTROL;LS21DP,ABS,T1.0,HB,GR70 (CL 1 S.N.A
M0215 BN07-00230A LCD-PANEL;LTM210M2-L02,Dvorak,8BIT,477.6 1 SA
M0006 BN96-03195A ASSY SHIELD P-COVER;LS21DPW,SECC,T0.8 1 SNA
M0174 BN44-00127B IP BOARD;FSP060-1PI01,214T,2.0 ~3.0mA,7. 1 SA
M0014 BN94-00846P ASSY PCB MAIN-SPZ,W/W;LS21DPW* 1 SA
T0376 BN63-02473A SHIELD-VIDEO;LS215TW,SPTE,T0.3 1 SNA
M0006 BN63-02470A COVER-REAR;LS215TW,HIPS,T2.3,HB,BK24 1 SNA
M0003 BN96-03196A ASSY STAND P;LS21DPW,HIPS HB,BK24 1 SA
To Next Page
