Samsung 215TW - SyncMaster - 21" LCD Monitor

6 Electrical Parts List
6-15
....4 Q601 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23, 1 S.A
....4 R216 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 F103 2901-001114 FILTER-EMI SMD;25VDC,2.0ADC,-,100nF,3.2x 1 S.A
....4 F103 2901-001114 FILTER-EMI SMD;25VDC,2.0ADC,-,100nF,3.2x 1 S.A
....4 CN501 3711-005503 HEADER-BOARD TO CABLE;BOX,9P,1R,2mm,SMD- 1 S.A
....4 R651 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 1 S.A
....4 R652 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 1 S.A
....4 R653 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R654 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R655 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R656 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R657 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R658 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R659 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R660 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R661 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R662 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R663 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R664 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R665 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R666 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R667 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 R668 2007-000100 R-CHIP;68Kohm,5%,1/10W,TP,1608 1 S.A
....4 T0568 3301-001148 BEAD-SMD;60ohm,1608,TP,-,- 1 S.N.A
...3 T0099 BN62-00003A HEAT SINK-IC;NK,SUN,A6063S,T2.5,W28,L28, 1 S.N.A
..2 M0006 BN96-03195A ASSY SHIELD P-COVER;LS21DPW,SECC,T0.8 1 S.N.A
...3 BN63-01774A SHIELD-INSULATOR;BI17/19BS,PET,T0.35 1 S.N.A
...3 M0107 BN63-02472A SHIELD-COVER;LS215TW,SECC,T0.8 1 S.N.A
..2 M2893 BN39-00666B LEAD CONNECTOR;LS20BRBASZ,UL1571#30,30p, 1 S.A
..2 M0174 BN44-00127B IP BOARD;FSP060-1PI01,214T,2.0 ~3.0mA,7. 1 S.A
..2 CCMM1 BN73-00091D SILICON/RUBBER;LBR20BS/CS,SILICON+ALUMIN 1 S.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 4 S.N.A
0.1 M0113 BN92-01619R ASSY P/MATERIAL;LS21DPWAB/XAA 1 S.N.A
..2 T0376 6902-000061 BAG AIR;LDPE,T0.2,L1000,W500,TRP,,, 0.01 S.N.A
..2 T0524 6902-000358 BAG PE;HDPE/NITRON(DOUBLE),T0.02/T0.5,W9 1 S.N.A
..2 T0376 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,-,-- 0.003 S.N.A
..2 P/M 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 2.3 S.N.A
..2 M0081 6902-000609 BAG ROLL;LDPE,T0.05,W2400,L1000,TRP,-,- 0.055 S.N.A
0.1 M0019 BN92-01681N ASSY LABEL;LS21DPW*,W/W 1 S.N.A
0.1 M0003 BN92-01698Y ASSY BOX;LS21DPWASQ/EDC 1 S.N.A
..2 BOX BN69-01333A BOX-MONITOR;S/M215TW(LS21DPW),SY-05,YEL, 1.02 S.N.A
0.1 M0045 BN92-01720K ASSY ACCESSORY;LS21DPWASQ/EDC 1 S.N.A
..2 M0114 BN39-00244B CBF SIGNAL;MO15PS,15P/15P,20276-N,1830mm 1 S.A
..2 M0125 BN39-00246F CBF SIGNAL-DVI(D);1703FP,24P/24P,20276-D 1 S.A
..2 M0045 BN96-03262M ASSY ACCESSORY;LS21DPWASQ/EDC 1 S.A
...3 T0268 3903-000042 CBF-POWER CORD;DT,EU,FP3/YES,IEC320 C13/ 1 S.A
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2 1 S.N.A
...3 ACCESSORY BH68-70438A CARD-12,BLOC WARRANTY;TFT LCD,BASIC,EU,M 1 S.N.A
...3 ACCESSORY BH68-70448A CARD-01;TFT LCD,SRC,RUSSIA,S/W,120,W210* 1 S.N.A
...3 T0059 BN68-00907A MANUAL FLYER-CARD;COMM,SAMSUNG,18 LANG,E 1 S.N.A
...3 M0215 BN96-03197A ASSY MANUAL P-IB+QSG;215TW,SyncMaster,W/ 1 S.N.A
....4 QSG BH68-00376L MANUAL FLYER-04,QSG;LCDQUICK SETUP GUIDE 1 S.N.A
....4 IB BN59-00520A S/W DRIVER-01,IB;215TW,W/W,SyncMaster,Do 1 S.N.A
Level Loc. No. Code No. Description & Specification EA SA/SNA
