English-7
Connecting a PC
TV Rear Panel
1
D-Sub Cable (Not supplied)
2
PC Audio Cable (Not supplied)
PC
1
Connect a D-Sub Cable between
PC IN [PC] connector on the TV
and the PC output connector on
your computer.
2
Connect a PC Audio Cable
between the PC IN [AUDIO] jack
on the TV and the Audio Out jack of
the sound card on your computer.
Each PC has a different back panel
configuration.
When connecting a PC, match the
color of the connection terminal to the
cable.
When using an HDMI/DVI cable
connection, you must use the HDMI
IN 2 jack.
°
°
°
Using the D-Sub Cable
1
Connect an HDMI/DVI cable between
the HDMI IN 2 jack on the TV and
the PC output jack on your computer.
2
Connect a 3.5 mm Stereo mini-
plug/2RCA Cable between the DVI
IN(HDMI2) [R-AUDIO-L] jack on the
TV and the Audio Out jack of the
sound card on your computer.
Using the HDMI/DVI Cable
TV Rear Panel
PC
1
HDMI/DVI Cable (Not supplied)
2
3.5 mm Stereo mini-plug/2RCA Cable (Not supplied)
