..2 M0006 BN96-01607A ASSY SHIELD P-COVER;MH17FS,SECC T0.5,EL/ 1
...3 CIS BN63-01386A SHIELD-MEMORY;730MP,SECC,T0.5 1 S.N.A
...3 CIS BN63-01602A FELT-VIBRATION;MH17FS,EVA,T2.0,6,20,BLAC 2 S.N.A
...3 CIS BN63-01603A FELT-VIBRATION;MH17FS,EVA,T0.5,10,176,BL 1 S.N.A
..2 CCM1 6001-000781 SCREW-MACHINE;PH,+,M3,L8,ZPC(BLK),SWRCH1 1 S.N.A
0.1 M0017 BN91-00808J ASSY CHASSIS-ATH;MH17FSW(WISE-LINK) 1
..2 M0014 BN94-00539X ASSY PCB MAIN-ATH;MH17FS 1
...3 T0245 0202-001366 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb, 0.25 S.N.A
...3 IC012 1203-000165 IC-POSI.ADJUST REG.;78R12,TO-220,4P,-,PL 1
...3 FT707 2904-001179 FILTER-SAW;36.125MHz,-,32.65-39.6MHz/0.5 1
...3 CN102 3701-001224 CONNECTOR-DVI;24P,3R,FEMALE,STRAIGHT,AU1 1
...3 CN101 3701-001302 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1
...3 CN906 3705-001331 CONNECTOR-COAXIAL;PAL,ADAPTOR(J/J),-,75o 1
...3 CN906 3711-004183 CONNECTOR-HEADER;BOX,10P,1R,-,ANGLE,SN 1
...3 CN906 3711-004349 CONNECTOR-HEADER;BOX,3P,1R,2MM,STRAIGHT, 1
...3 CN906 3711-004445 CONNECTOR-HEADER;BOX,60P,3R,1mm,ANGLE,AU 1
...3 CN906 3711-004712 CONNECTOR-HEADER;BOX,9P,1R,2mm,STRAIGHT, 1
...3 CN906 3711-005505 CONNECTOR-HEADER;NOWALL,11P,1R,2.54mm,AN 1
...3 CN703 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1
...3 CN706 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1
...3 CN701 3722-001734 JACK-VHS;4P,-,SN,BLK,- 1
...3 CN705 3722-001844 JACK-PIN;3P,8.3MM,AU,YEL/WHT/RED,- 1
...3 CN700 3722-001845 JACK-PIN;3P,8.3MM,AU,GRN/BLU/RED,- 1
...3 CN707 3722-001846 JACK-PIN;2P,8.3MM,AU,WHT/RED,- 1
...3 CN708 3722-001931 JACK-PIN;1P,-,AU,BLK,- 1
...3 CN100 3722-002176 JACK-PHONE;7P/4C,-,SN,L-BLU,- 1
...3 CIS3 BN40-00052A TUNER;TECC0849FL40B(S),NTSC,181CH,38.9MH 1
...3 TUNER_PCB BN41-00392A PCB SUB;KD17AS,FR4,2L,MP1.0,1.6T,54*13 1 S.N.A
...3 T0174 BN97-00384F ASSY SMD;MH17FS 1 S.N.A
....4 ZD100 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225MW,SOT-2 1
....4 ZD101 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225MW,SOT-2 1
....4 ZD103 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225MW,SOT-2 1
....4 ZD104 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225MW,SOT-2 1
....4 ZD402 0403-000277 DIODE-ZENER;MMBZ5226B,3.14-3.47V,225MW,S 1
....4 ZD600 0403-001382 DIODE-ZENER;UDZ33B,32.15-33.79V,200MW,SO 1
....4 ZD102 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1
....4 ZD105 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1
....4 ZD400 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1
....4 ZD401 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1
....4 ZD700 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1
....4 ZD701 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1
....4 ZD702 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1
....4 ZD703 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1
....4 ZD712 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1
....4 ZD718 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1
....4 ZD106 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1
....4 ZD107 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1
....4 ZD704 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1
....4 ZD705 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1
....4 ZD706 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1
....4 ZD707 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1
....4 ZD708 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1
....4 ZD709 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1
....4 ZD710 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1
....4 ZD711 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1
....4 ZD713 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1
....4 ZD714 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1
....4 ZD715 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1
....4 Q700 0501-000280 TR-SMALL SIGNAL;KSA1182,PNP,150mW,SOT-23 1
....4 Q704 0501-000280 TR-SMALL SIGNAL;KSA1182,PNP,150mW,SOT-23 1
....4 Q705 0501-000280 TR-SMALL SIGNAL;KSA1182,PNP,150mW,SOT-23 1
....4 Q706 0501-000280 TR-SMALL SIGNAL;KSA1182,PNP,150mW,SOT-23 1
7 Electrical Parts List
7-2
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
To Next Page
