...3 CN300 3722-002213 JACK-USB;4P/2C,AU30U,BLK,ANGLE,A TYPE(RE 1
...3 CIS6 BN63-01391A SHIELD-KIT TOP;730MP,SUS,T0.5 1 S.N.A
...3 CIS7 BN63-01392A SHIELD-KIT BOTTOM;730MP,SUS,T0.5 1 S.N.A
...3 CIS8 BN63-01519A COVER-FRAME;MH17FS,ABS,HB,BK07 1 S.N.A
...3 T0174 BN97-00407A ASSY SMD;MH17FSW(WISE-LINK) 1 S.N.A
....4 Q300 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1
....4 Q301 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1
....4 Q900 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1
....4 Q901 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1
....4 IC104 0801-002404 IC-CMOS LOGIC;74VHC4066,ANALOG SWITCH,SO 1
....4 T0596 0904-001881 IC-USC;USB20H04,-,TQFP,64P,10x10x1.4,24M 1
....4 IC113 1105-001308 IC-DRAM;4S281632E,2MX16X4BIT,TSOP,54P,40 1
....4 IC113 1105-001308 IC-DRAM;4S281632E,2MX16X4BIT,TSOP,54P,40 1
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1
....4 T0087 1203-002844 IC-POSI.FIXED REG.;AP1117D-18A,TO-252-3L 1
....4 T0087 1203-002945 IC-POSI.FIXED REG.;AP1117E25A,SOT-223,3P 1
....4 IC904 1203-002997 IC-VOL. DETECTOR;ELM7529CBA-S,SOT-23,3P, 1
....4 IC909 1204-002310 IC-DECODER;MA8201A,LQFP,44P,10x10mm,PLAS 1
....4 IC902 1205-002520 IC-CONTROLLER;MX88V610AXC,BGA,180P,12x12 1
....4 R9008 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1
....4 R9009 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1
....4 R946 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1
....4 R315 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R321 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R322 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R325 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R331 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R339 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R340 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R9003 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R9017 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R9020 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R9021 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R9022 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R9023 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R9024 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R9025 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R9026 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R9027 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R9029 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R9030 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R9031 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R9033 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R906 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R907 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R908 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R909 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R910 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R911 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R912 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R913 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R914 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R915 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R916 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R920 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R921 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R930 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R931 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R934 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R957 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R958 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R959 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
....4 R962 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1
7 Electrical Parts List
7-15
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
To Next Page
