....4 T0568 3301-001145 BEAD-SMD;60OHM,4516,6000,TP,70OHM/45MHZ, 1 S.N.A
....4 CN905 3709-001283 CONNECTOR-CARD SLOT;24P,2.54mm,SMD-A,AU1 1
....4 CN903 3709-001287 CONNECTOR-CARD SLOT;10P,1.5mm,SMD-A,AU10 1
....4 CN906 3709-001289 CONNECTOR-CARD SLOT;9P,2.425/2.5/1.7mm,S 1
....4 CN904 3709-001290 CONNECTOR-CARD SLOT;50P,1.27mm,SMD-A,AU1 1
....4 CN906 3711-000556 CONNECTOR-HEADER;BOX,12P,1R,1.25mm,SMD-A 1
....4 CN906 3711-002049 CONNECTOR-HEADER;BOX,6P,1R,1.25mm,SMD-A, 1
....4 IC302 1205-002473 IC-SWITCH;AAT4626IHS-T1,TSSOP,8P,4.4x3mm 1
....4 FT305 2704-000010 INDUCTOR-SMD-ARRAY;70ohm,100V,600mA,-,0. 1
....4 M0018 BN97-00400S ASSY MICOM;MH17FSW 1
.....5 IC115 1107-001087 IC-FLASH MEMORY;29LV160,1Mx16/2Mx8,TSOP, 1
....4 D300 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO 1
....4 D301 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO 1
....4 D302 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO 1
....4 D303 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO 1
....4 D304 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO 1
....4 D305 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO 1
....4 D306 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO 1
....4 D307 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO 1
....4 D308 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO 1
....4 D309 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO 1
....4 D310 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO 1
....4 D311 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO 1
....4 D900 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO 1
....4 T0087 1203-002853 IC-POSI.FIXED REG.;G960T45R,TO-252,3P,6. 1
....4 R302 2007-000503 R-CHIP;2.2ohm,5%,1/10W,TP,1608 1
....4 R303 2007-000503 R-CHIP;2.2ohm,5%,1/10W,TP,1608 1
....4 R304 2007-000503 R-CHIP;2.2ohm,5%,1/10W,TP,1608 1
....4 R305 2007-000503 R-CHIP;2.2ohm,5%,1/10W,TP,1608 1
....4 R334 2007-000503 R-CHIP;2.2ohm,5%,1/10W,TP,1608 1
....4 R335 2007-000503 R-CHIP;2.2ohm,5%,1/10W,TP,1608 1
....4 C333 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1
....4 C334 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1
....4 C303 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,1608 1
....4 X900 2801-004211 CRYSTAL-SMD;13.5MHZ,25PPM,28-AAN,20PF,40 1
....4 T0568 3301-001594 BEAD-SMD;90ohm,2.0*1.2*1.3mm,-,TP,-,-,- 1 S.N.A
....4 Q409 0505-001170 FET-SILICON;SI9933ADY-T1,P,-20V,3.4A,0.0 1
....4 C347 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1
....4 C349 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1
....4 X901 2804-001370 OSCILLATOR-CLOCK;48MHz,100ppm,10TTL & CM 1
....4 C309 2402-001155 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM 1
....4 C311 2402-001155 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM 1
....4 MP1.2 BN41-00502C PCB-INTERFACE;MH17FS,FR4,6 layer,MP1.2,1 1 S.N.A
....4 CIS5 0202-001375 SOLDER-CREAM;RMA-20-21L,S63,-,Sn63/Pb36. 1.75 S.N.A
...3 CCM1 6001-000781 SCREW-MACHINE;PH,+,M3,L8,ZPC(BLK),SWRCH1 4 S.N.A
0.1 M0019 BN92-00962A ASSY LABEL;MH17NS 1 S.N.A
0.1 M0113 BN92-01071J ASSY P/MATERIAL;MH17FS 1 S.N.A
..2 T0376 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,-,-- 0.034 S.N.A
..2 T0524 6902-000520 BAG PE;HDPE/NITRON(DOUBLE),T0.015/T0.5(D 1 S.N.A
..2 P/M 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 3 S.N.A
..2 M0081 6902-000609 BAG ROLL;LDPE,T0.05,W2400,L1000,TRP,-,- 0.1 S.N.A
0.1 M0003 BN92-01205L ASSY BOX;MH17FSSSU/XSA 1 S.N.A
..2 BOX BN69-00858A BOX-03;S/M730MP(MH17FS),W/W,SW4,YEL,A-1, 1.01 S.N.A
..2 M0120 BH75-10529A UNIT-HANDLE PACKING;LXA410TLMU,PE,-,WHIT 1 S.N.A
...3 M0103 BN72-60001A LEVER-TOP;LSD210TL,PE-LD,WHITE,TFT_LCD 1 S.N.A
...3 M0102 BN72-60002A LEVER-BOTTOM;LSD210TL,PE-LD,WHITE,TFT-LC 1 S.N.A
0.1 M0045 BN92-01417J ASSY ACCESSORY;LS17MHFSSU/XAZ,MH17FS 1 S.N.A
..2 M0045 BN96-02194W ASSY ACCESSORY;LS17MHFSSU/XAZ,MH17FS 1
...3 CN906 3705-001191 CONNECTOR-COAXIAL;PAL,ADAPTER(J/P),30moh 1
7 Electrical Parts List
7-19
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
