Samsung 730MP - 2-2 Pin Assignments

2 Product Specifications
2-2 730MP
2-2 Pin Assignments
Sync
Type
Pin No.
Separate H/V Composite H/V
15 Pin signal cable connector
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Red
Green
Blue
No Connection
GND (DDC Return)
GND-Red
GND-Green
GND-Blue
No Connection
GND-Sync/Self Test
No Connection
DDC Data
Horizontal Sync
Vertical Sync
DDC Clock
Red
Green
Blue
No Connection
GND (DDC Return)
GND-Red
GND-Green
GND-Blue
No Connection
GND-Sync/Self Test
No Connection
DDC Data
H/V Sync
Not Used
DDC Clock
Sync
Type
Pin No.
24 - Pin DVI - D (TMDS)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Rx2-
Rx2+
GND
No Connection
No Connection
DDC Clock (SCL)
DDC Data (SDA)
No Connection
Rx1-
Rx1+
GND
No Connection
No Connection
DDC Power Input (+5V)
Self Raster
Connection Signal Output (+5V)
Rx0-
Rx0+
GND
No Connection
No Connection
GND
RxC+
RxC-
