7
English
HG890 Model
Stand Components
When installing the stand, use the provided components and parts.
1EA
A B D
×12(M4×L14)
C
2EA
2EA
1
3
5
2
4
6
X 8 (M4 X L14)
C
− Lay the TV on a soft surface, screen down.
− Use the packing marerial to protect the screen.
X 4
(M4 X L14)
C
− Make sure to distinguish between the front and back of the Stand and the Stand Guide when assembling them.
− Make sure that at least two people lift and move the TV.
To Next Page
