Samsung 910MP - Alignments and Adjustments; DDC Jig Installation and Execution

4 Alignments and Adjustments
4-1
4 Alignments and Adjustments
This section describes to adjust LCD monitor after replacing EEPROM, Main PBA or Panel.
4-1 DDC jig installation
4-2 How to execute DDC
1. Execute "WinDDC.exe"
Monitor
(need to adjust)
PC system
(to input DDC data)
Parallel Cable
(25Pin)
MTI-2055
DDC Manager
Signal Cable
