Samsung 910MP - Electrical Parts List; Main PCB Components

7 Electrical Parts List
7-1
0 MZ19FS
1 STZ-MZ19FS - 1 SDI,TN-ZPD -
3 BN94-00642A - ASSY PCB MAIN MZ19FS SNA
4 0204-002420 CIS3 SOLVENT 1M-1000,C3H70H,96,-,- SNA
4 0204-002426 CIS2 FLUX DF-201TVS,MIX,0.820,FLUX 13%, 14KG,- SNA
4 2904-001179 FT700 FILTER-SAW 36.125MHz,-,32.65-39.6MHz/0.5dB,SIP5K,+-0MHz/21.8dB,31.25MHz/37dB SA
4 3701-001219 CN101 CONNECTOR-DSUB 15P,3R,FEMALE,ANGLE,AUF SA
4 3711-004531 CN202 CONNECTOR-HEADER BOX,10P,1R,2mm,ANGLE,SN SA
4 3711-004712 CN600 CONNECTOR-HEADER BOX,9P,1R,2mm,STRAIGHT,SN SA
4 3711-005505 CN700 CONNECTOR-HEADER NOWALL,11P,1R,2.54mm,ANGLE,SN,WHT SA
4 3722-000143 CN509 JACK-PHONE 1P(VER),3.4PI,AG,BLK,NO SA
4 3722-000183 CN506 JACK-SCART 21P,4mm,SN,BLK,NO SA
4 3722-002081 CN507 JACK-EAR PHONE 5P/2C,-,SnPb,L-BLU,- SA
4 3722-002267 CN508 JACK-PIN 3P,AU,RED/WHT/YEL,ANGLE SA
4 3722-002275 CN713 JACK-DIN 4P,-,SN,BLK,- SA
4 6046-001007 CIS STAND OFF M3,L5,NI PLT,SUM24L,#4-40 SNA
4 AA40-00025A TUNER TUNER-F/S
TDQ-6F/125S,PAL,181CH,38.9MHZ,75OHM,75OHM,DIN-JACK,ASYMM,5V,TR SA
4 BN39-00513A CIS7 LEAD CONNECTOR
MJ17AS(BS),UL1571#30,UL/CSA,30P,160MM,#30,1635L-30,12507HS-30L,BK,1571#30,SJ03- 0SA
4 BN41-00392A TUNER_PCB PCB SUB KD17AS,FR4,2L,MP1.0,1.6T,54*13 SNA
4 BN97-00488A - ASSY SMD MZ19FS SNA
5 0401-001056 D100 DIODE-SWITCHING MMBD4148SE,100V,200MA,SOT-23,TP SA
5 0401-001056 D101 DIODE-SWITCHING MMBD4148SE,100V,200MA,SOT-23,TP SA
5 0401-001056 D103 DIODE-SWITCHING MMBD4148SE,100V,200MA,SOT-23,TP SA
5 0401-001056 D104 DIODE-SWITCHING MMBD4148SE,100V,200MA,SOT-23,TP SA
5 0401-001056 D105 DIODE-SWITCHING MMBD4148SE,100V,200MA,SOT-23,TP SA
5 0401-001056 D706 DIODE-SWITCHING MMBD4148SE,100V,200MA,SOT-23,TP SA
5 0401-001056 D707 DIODE-SWITCHING MMBD4148SE,100V,200MA,SOT-23,TP SA
5 0401-001056 D708 DIODE-SWITCHING MMBD4148SE,100V,200MA,SOT-23,TP SA
5 0402-000553 D601 DIODE-RECTIFIER SS24,40V,2.0A,DO-214AA SA
5 0402-000553 D603 DIODE-RECTIFIER SS24,40V,2.0A,DO-214AA SA
5 0403-000579 D102 DIODE-ZENER BZX84C5V1,4.8-5.4V,200MW,SOT-23,TP SA
5 0403-000579 D106 DIODE-ZENER BZX84C5V1,4.8-5.4V,200MW,SOT-23,TP SA
5 0403-000579 D107 DIODE-ZENER BZX84C5V1,4.8-5.4V,200MW,SOT-23,TP SA
5 0403-000579 D108 DIODE-ZENER BZX84C5V1,4.8-5.4V,200MW,SOT-23,TP SA
5 0403-000579 D109 DIODE-ZENER BZX84C5V1,4.8-5.4V,200MW,SOT-23,TP SA
5 0403-000579 D120 DIODE-ZENER BZX84C5V1,4.8-5.4V,200MW,SOT-23,TP SA
5 0403-000579 D124 DIODE-ZENER BZX84C5V1,4.8-5.4V,200MW,SOT-23,TP SA
5 0403-000579 D211 DIODE-ZENER BZX84C5V1,4.8-5.4V,200MW,SOT-23,TP SA
5 0403-001382 ZD700 DIODE-ZENER UDZ33B,32.15-33.79V,200MW,SOD-323,TP SA
5 0403-001435 D210 DIODE-ZENER QZX363C5V6,5.32-5.88V,200MW,SOT-363,TP SA
5 0403-001435 D514 DIODE-ZENER QZX363C5V6,5.32-5.88V,200MW,SOT-363,TP SA
5 0406-001163 D501 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD SA
5 0406-001163 D503 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD SA
5 0406-001163 D507 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD SA
5 0406-001163 D508 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD SA
5 0406-001163 D509 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD SA
5 0406-001163 D510 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD SA
5 0406-001163 D511 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD SA
5 0406-001163 D512 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD SA
5 0406-001163 D513 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD SA
5 0406-001163 D515 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD SA
5 0406-001163 D516 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD SA
5 0406-001163 D517 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD SA
Level Code No. Loc. No. Description Specification Remarks
7 Electrical Parts List
❈ You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
7-1 Main PCB Parts
