10 PCB Layout
10-2
Loc. No. Description X Y
D100 DIODE-SWITCHING 7.5 28.6
D101 DIODE-SWITCHING 9.7 41.1
D102 DIODE-ZENER 11.8 28.6
D103 DIODE-SWITCHING 31.1 13
D104 DIODE-SWITCHING 22.3 13
D105 DIODE-SWITCHING 26.7 13
D106 DIODE-ZENER 14.5 13.1
D107 DIODE-ZENER 18.3 13.1
D108 DIODE-ZENER 18.8 24.3
D109 DIODE-ZENER 15 24.3
D120 DIODE-ZENER 37.809 14.392
D124 DIODE-ZENER 37.73 22.675
D210 DIODE-ZENER 210.5 7.5
D211 DIODE-ZENER 219.6 8.5
D501 DIODE-TVS 46.17 13.494
D503 DIODE-TVS 41.97 13.494
D507 DIODE-TVS 56.5 13.1
D508 DIODE-TVS 58.6 13.1
D509 DIODE-TVS 78.5 13.1
D510 DIODE-TVS 79.8 19
D511 DIODE-TVS 87.4 19
D512 DIODE-TVS 93.4 18.6
D513 DIODE-TVS 96 19
D514 DIODE-ZENER 74.9 13.1
D515 DIODE-TVS 107.5 16.2
D516 DIODE-TVS 135.20414 12.19396
D517 DIODE-TVS 107.6 13
D518 DIODE-TVS 141.4 12.1
D601 DIODE-RECTIFIER 92.1 77
D603 DIODE-RECTIFIER 180.9 93.3
D703 DIODE-TVS 141.1 17.6
D704 DIODE-TVS 146.3 17.6
D705 DIODE-TVS 149.8 17.6
D706 DIODE-SWITCHING 137.1 23.1
D707 DIODE-SWITCHING 141.2 23.1
D708 DIODE-SWITCHING 133 23.1
ZD700 DIODE-ZENER 159.4 21
IC55 IC-AUDIO AMP 208.5 83
IC100 IC-EEPROM 9.9 33.6
IC201 IC-EEPROM 103.75 76.35
IC202_SOCK SOCKET-IC 118.7 88.6
IC202 IC-EPROM 118.7 88.6
IC300 IC-LCD CONTROLLER 39 53.5
IC302 IC-DRAM 65.2 71.4
IC504 IC-AUDIO AMP 164.9 28.75
IC601 FET-SILICON 20.1 85.8
IC602 IC-DC/DC CONVERTER 89.4 89.6
IC603 IC-DC/DC CONVERTER 160.4 90.6
IC605 IC-POSI.FIXED REG. 154.014 77.494
IC606 IC-POSI.FIXED REG. 67.6 51
IC607 IC-POSI.FIXED REG. 85.9 46.2
IC609 IC-POSI.FIXED REG. 162.466 64.6
DIODE
Loc. No. Description X Y
IC610 FET-SILICON 67.3 28
IC700 IC MICOM 121.6 55.6
IC701 IC-VOL. DETECTOR 126.30907 25.62588
IC702 IC-CMOS LOGIC 107.8 26
IC703 IC-CMOS LOGIC 146.2 34.5
Q100 TR-SMALL SIGNAL 20.8 31.2
Q300 TR-SMALL SIGNAL 16.1 65.2
Q305 TR-SMALL SIGNAL 59 37
Q501 TR-SMALL SIGNAL 67.2 13.3
Q502 TR-SMALL SIGNAL 200 93.2
Q505 TR-SMALL SIGNAL 170.7 21
Q512 TR-SMALL SIGNAL 62.9 13.2
Q513 TR-SMALL SIGNAL 170.4 30.4
Q600 TR-SMALL SIGNAL 17.1 72.7
Q601 TR-SMALL SIGNAL 22 72.4
Q603 TR-SMALL SIGNAL 64.5 40.4
Q604 TR-SMALL SIGNAL 147.7 88.4
IC
TRANSISTOR
