Samsung 910MP - Timing Chart

2 Product Specifications
2-3
2-3 Timing Chart
This section of the service manual describes the timing that the computer industry recognizes as standard for
computer-generated video signals.
Table 2-1 Timing Chart
Definition of Terms
Video
HSync
Sync Sync
Sync
Time
Blanking
Blank Srart
Sync Srart
Blank Time
Back
Porch
Back
Porch
Top/Left
Border
"Activer"Video
Bottom/Right
Border
"Addressable"Video
(Addr Time)
Front
Porch
YSync
