Disassembly and Reassembly

3-14 Samsung Electronics

No Parts Procedure Remark

1 PANEL

FILTER

(cont.)

9) Remove the 2 screws fixed in STEP

MOTOR and then remove the MOTOR.

(Use +Screw Driver)

10) Separate the BLADE H.
