Samsung AC024BNHDCH - Indoor Unit Disassembly - 4 way Cassette (Panel)

Disassembly and Reassembly
Samsung Electronics 3-15
No Parts Procedure Remark
1 PANEL
&
FILTER
1) Press the PUSH BUTTON and open the
GRILL.
2) First, remove the clip from the PANEL.
And then incline the GRILLE by 90˚ and
separate the GRILLE from the PANEL.
3) Separate the FILTER from the PANEL.
4) Remove the 4 COVER SCREW.
5) Remove the 7 screws fixed in PANEL and
then separate from the indoor unit.
(Use +Screw Driver)
