Disassembly and Reassembly
Samsung Electronics 3-21
No Parts Procedure Remark
1 Panel
1) Pull two levers below Samsung logo to
open the grille.
2) Detach the safety clip and white link
from the panel.
3) Remove the 2 fixed screws to remove
the Control-B ox Cover.
(Use +Screw Driver)
4) Remove the 4 connector wires from
the PBA. (Remocon-Receiver, Blade
motor and Humidity sensor)
5) Detach the 4 corners of the panel
using both hands..
■ 4way CST : AC***BN4DCH
To Next Page
