Samsung Electronics 3-11
No Parts Procedure Remark
2
Drain Pan
1)
Separate 5 fixing screws in the Drain Pan.
(Use +Screw Driver.)
2)
Pull the Drain Pan to separate it from the
Indoor Unit.
When separating the Pan please be careful not
to touch the board of Heat Exchanger.
3
Control In
1)
Undo 3 fixing screws in the Control In
appliance part to separate the Cover.
(Use +Screw Driver.)
To Next Page
