Samsung AD24A1(B1)E12 - View of the Indoor Unit; View of the Outdoor Unit

View of the Indoor Unit
OPERATION
TURBO
FAN
TIMER
ON/OFF switch
(operation without
remote control)
Air Filter
(under the grille)
TIMER indicator
- YELLOW
OPERATION indicator
- Operation : GREEN
- Deice : RED
TURBO indicator
- RED
FAN indicator
- GREEN
Air flow blades (outlet)
Remote control sensor
Air Inlet
View of the Outdoor Unit
Air Inlet
Air Outlet
Connection Valve
E-4
UD18A1(B1)E2
UD19A1(B1)E2
XMH18ZV
XMH19ZV
MH19YA1X
UD24A1(B1)E2
XMH24ZV
❄ The design and shape are subject to change according to the model.
