4-3-2 PCB Box
■ Parts List
No
1
2
2-1
2-2
2-3
2-4
2-5
2-6
3
CODE NO
DB61-10151A
DB93-10586A
DB93-10627A
DB09-10149A
DB32-10008D
DE26-20154A
2306-000294
3501-001058
DE32-10037A
DB93-10560B
Description
CASE-CONTROL
ASS'Y MAIN PCB
Ò
IC - MCU
THERMISTOR ASS'Y
TRANS-POWER
C-FILM
POWER-RELAY
FUSE
ASS'Y PCB DISPLAY
Specification
ABS(94-5V)
ASSÕY
Ò
MB89635R-466
103AT
AC230V DC17V 300mA
CFS 99N 450VAC 155K
DI1U DC12V
250V 3.15A
-
QÕTY
AD26A1C13 AD18A1C09
1
-
1
1
1
1
1
1
1
1
1
1
-
1
1
1
1
1
1
1
Remark
1
2-4
2-6
2-2
2-1
2
3
2-5
2-3
