4-3-3 AssÕy Display & Module
■ DB93-10560B
■ PCB-DISPLAY : DB41-10204B
■ Parts List
No
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
CODE NO
PCB-DISPLAY
LED-LAMP
LED-LAMP
LED-LAMP
LED-LAMP
MODULE REMOCON
C-CERAMIC
R-CARBON
CONNECTOR WAFER
C-CERAMIC
DIODE SWITCHING
C/W DIS & MODULE
CASE-CENTER PCB UP
CASE-CENTER PCB LOW
SEAL DISPLAY UPP
SEAL CASE DISPLAY
Description
DB41-10204B
0601-001333
0601-001059
0601-001060
0601-001196
DB32-50027A
2202-000780
2001-000515
2201-000283
0401-000005
DB39-20346A
DB61-10191A
DB63-10494A
DB72-10233A
DB72-10220F
Specification
FR-1 T1.6 W20 L170
LTL-30EHJ(ORG/GRN)
SY5511(YEL)
SM5511(GRN)
SO5511(ORG)
PNA4612M¿¿MD
CA OA 50V 104Z
RD 1/8TP 221-J
YWLA200-09P
CA OA 50V 102Z
1N4148
UL1007 AWG#26/9
PC,BLUE
ABS,BLK
FOAM-PE,BLK
30 FOAM-PE
QÕTY
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
Remark
