Name of Each Part
The design and shape can be changed according to the model.
Indoor Unit
Air filter
(under the panel)
Airflow blades
(outlet)
Air Inlet
Room
Temperature sensor
Power(On/Off)
button
Turbo
indicator
Power(On/Off)
button
Operation
indicator
Timer/Good Morning mode
indicator
Set temperature &
room temperature
Auto cleaning
indicator
Fan speed
indicator
Energy saving
indicator
