Samsung AQ09MSBX - Outdoor Unit Identification; Outdoor Unit Components

E-9
ENGLISH
Name of Each Part
Outdoor Unit
AQ09M

Series
Air Outlet
Connection Valve
(Inside)
Air Inlet (Rear)
Power(On/Off)
button
AQ12M

Series
Outdoor Unit
AQ18M

Series
Air Inlet (Rear)
Air Outlet
Connection Valve
(Inside)
Outdoor Unit
AQ24M

Series
Air Outlet
Air Inlet (Rear)
Connection Valve
(Inside)
