Samsung AR09TXEAAWKNEU - Page 166

166
12. Capacity Table
Combination
(Capacity Index)
Combination
(Total)
Combination
(%)
Outdoor
Temperature
(℃,DB)
Indoor Temperature(℃, WB)
14 16 18 19 20 22 24
TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW)
2500 3500 5000 11000 162%
10 7.65 1.45 7.95 1.48 8.25 1.51 8.41 1.52 8.56 1.54 8.87 1.57 9.19 1.60
12 7.51 1.48 7.81 1.52 8.12 1.55 8.27 1.56 8.43 1.58 8.74 1.61 9.06 1.64
14 7.38 1.52 7.68 1.55 7.99 1.59 8.14 1.60 8.30 1.62 8.61 1.65 8.93 1.68
16 7.25 1.56 7.55 1.60 7.86 1.63 8.01 1.64 8.17 1.66 8.48 1.69 8.80 1.72
18 7.12 1.60 7.42 1.64 7.73 1.67 7.88 1.68 8.04 1.70 8.35 1.73 8.68 1.76
20 6.99 1.65 7. 29 1.68 7.60 1.71 7.75 1.73 7.91 1.74 8.23 1.77 8.55 1.81
21 6.92 1.67 7.22 1.70 7.53 1.73 7. 6 9 1.75 7.84 1.76 8.16 1.79 8.48 1.83
23 6.79 1.71 7.09 1.74 7.40 1.77 7.56 1.79 7.7 1 1.81 8.03 1.84 8.35 1.87
25 6.66 1.75 6.96 1.79 7.27 1.82 7.43 1.83 7. 5 9 1.85 7.90 1.88 8.23 1.92
27 6.53 1.80 6.83 1.83 7.14 1.86 7.30 1.88 7.46 1.90 7.78 1.93 8.10 1.96
29 6.40 1.84 6.70 1.87 7.01 1.91 7.17 1.92 7.33 1.94 7.65 1.97 7.9 7 2.01
31 6.27 1.89 6.57 1.92 6.89 1.95 7.04 1.97 7.20 1.99 7.52 2.02 7.85 2.05
33 6.14 1.93 6.45 1.97 6.76 2.00 6.92 2.02 7.07 2.03 7. 39 2.07 7.72 2.10
35 6.01 1.98 6.32 2.01 6.63 2.05 6.80 2.06 6.95 2.08 7.27 2.11 7. 5 9 2.15
37 5.88 2.03 6.19 2.06 6.50 2.10 6.66 2.11 6.82 2.13 7.14 2.16 7.47 2.20
39 5.75 2.08 6.06 2.11 6.38 2.14 6.53 2.16 6.69 2.18 7.02 2.21 7.34 2.25
42 5.56 2.15 5.87 2.19 6.19 2.22 6.34 2.24 6.50 2.25 6.83 2.29 7.15 2.32
44 5.43 2.20 5.74 2.24 6.06 2.27 6.22 2.29 6.38 2.30 6.70 2.34 7.03 2.37
46 5.31 2.25 5.62 2.29 5.93 2.32 6.09 2.34 6.25 2.36 6.58 2.39 6.91 2.42
3500 3500 3500 10500 154%
10 7.65 1.45 7.95 1.48 8.25 1.51 8.41 1.52 8.56 1.54 8.87 1.57 9.19 1.60
12 7.51 1.48 7.81 1.52 8.12 1.55 8.27 1.56 8.43 1.58 8.74 1.61 9.06 1.64
14 7.38 1.52 7.68 1.55 7.99 1.59 8.14 1.60 8.30 1.62 8.61 1.65 8.93 1.68
16 7.25 1.56 7.55 1.60 7.86 1.63 8.01 1.64 8.17 1.66 8.48 1.69 8.80 1.72
18 7.12 1.60 7.42 1.64 7.73 1.67 7.88 1.68
8.04 1.70 8.35 1.73 8.68 1.76
20 6.99 1.65 7. 29 1.68 7.60 1.71 7.75 1.73 7.91 1.74 8.23 1.77 8.55 1.81
21 6.92 1.67 7.22 1.70 7.53 1.73 7. 6 9 1.75 7.84 1.76 8.16 1.79 8.48 1.83
23 6.79 1.71 7.09 1.74 7.40 1.77 7.56 1.79 7.7 1 1.81 8.03 1.84 8.35 1.87
25 6.66 1.75 6.96 1.79 7.27 1.82 7.43 1.83 7. 5 9 1.85 7.90 1.88 8.23 1.92
27 6.53 1.80 6.83 1.83 7.14 1.86 7.30 1.88 7.46 1.90 7.78 1.93 8.10 1.96
29 6.40 1.84 6.70 1.87 7.01 1.91 7.17 1.92 7.33 1.94 7.65 1.97 7.9 7 2.01
31 6.27 1.89 6.57 1.92 6.89 1.95 7.04 1.97 7.20 1.99 7.52 2.02 7.85 2.05
33 6.14 1.93 6.45 1.97 6.76 2.00 6.92 2.02 7.07 2.03 7. 39 2.07 7.72 2.10
35 6.01 1.98 6.32 2.01 6.63 2.05 6.80 2.06 6.95 2.08 7.27 2.11 7. 5 9 2.15
37 5.88 2.03 6.19 2.06 6.50 2.10 6.66 2.11 6.82 2.13 7.14 2.16 7.47 2.20
39 5.75 2.08 6.06 2.11 6.38 2.14 6.53 2.16 6.69 2.18 7.02 2.21 7.34 2.25
42 5.56 2.15 5.87 2.19 6.19 2.22 6.34 2.24 6.50 2.25 6.83 2.29 7.15 2.32
44 5.43 2.20 5.74 2.24 6.06 2.27 6.22 2.29 6.38 2.30 6.70 2.34 7.03 2.37
46 5.31 2.25 5.62 2.29 5.93 2.32 6.09 2.34 6.25 2.36 6.58 2.39 6.91 2.42
NOTE
 Cooling capacity is based on 27°CDB / 19°CWB (indoor temperature), 35°CDB (outdoor temperature).
 Heating capacity is based on 20°CDB (indoor temperature), 7°CDB/6°CWB (outdoor temperature).
 The above is the value for connecting with the following indoor units.
- 2000, 2500, 3500, 5000W class : AR07TXFCAWKNEU, AR09TXFCAWKNEU, AR12TXFCAWKNEU, AR18TXEAAWKNEU
 Capacities are based on the following conditions:
- Corresponding refrigerant piping length : 5m / - Level difference : 0m
 The total ability of connected a indoor unit is up to 7.5kW
 It is impossible to connect the indoor unit for one room only.
 This data is reference data for temperature capacity trend.
