Samsung AR09TXEAAWKNEU - Page 198

198
12. Capacity Table
Combination
(Capacity Index)
Combination
(Total)
Combination
(%)
Outdoor
Temperature
(℃,DB)
Indoor Temperature(℃, WB)
14 16 18 19 20 22 24
TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW)
2500 2500 2500 3500 11000 138%
10 9.00 1.61 9.35 1.65 9.71 1.68 9.89 1.70 10.07 1.72 10.44 1.75 10.81 1.79
12 8.84 1.66 9.19 1.69 9.55 1.73 9.73 1.74 9.92 1.76 10.29 1.80 10.66 1.83
14 8.68 1.70 9.04 1.74 9.40 1.77 9.58 1.79 9.76 1.81 10.13 1.84 10.51 1.88
16 8.53 1.75 8.88 1.78 9.24 1.82 9.43 1.83 9.61 1.85 9.98 1.89 10.36 1.92
18 8.37 1.79 8.73 1.83 9.09 1.86 9.27 1.88 9.46 1.90 9.83 1.93 10.21 1.97
20 8.22 1.84 8.57 1.87 8.94 1.91 9.12 1.93 9.30 1.94 9.68 1.98 10.05 2.02
21 8.14 1.86 8.50 1.90 8.86 1.93 9.04 1.95 9.23 1.97 9.60 2.00 9.98 2.04
23 7.99 1.91 8.34 1.94 8.71 1.98 8.89 2.00 9.08 2.02 9.45 2.05 9.83 2.09
25 7.83 1.96 8.19 1.99 8.56 2.03 8.74 2.05 8.92 2.07 9.30 2.10 9.68 2.14
27 7.68 2.01 8.04 2.04 8.40 2.08 8.59 2.10 8.77 2.12 9.15 2.15 9.53 2.19
29 7.53 2.06 7.89 2.09 8.25 2.13 8.44 2.15 8.62 2.17 9.00 2.20 9.38 2.24
31 7.37 2.11 7. 74 2.14 8.10 2.18 8.29 2.20 8.47 2.22 8.85 2.25 9.23 2.29
33 7.22 2.16 7.58 2.20 7.95 2.23 8.14 2.25 8.32 2.27 8.70 2.31 9.08 2.34
35 7. 07 2.21 7.43 2.25 7.80 2.29 8.00 2.30 8.17 2.32 8.55 2.36 8.93 2.40
37 6.92 2.27 7.28 2.30 7.65 2.34 7.84 2.36 8.02 2.38 8.40 2.42 8.79 2.45
39 6.77 2.32 7.13 2.36 7.50 2.39 7.69 2.41 7.87 2.43 8.25 2.47 8.64 2.51
42 6.54 2.40 6.91 2.44 7.28 2.48 7.46 2.50 7.65 2.52 8.03 2.55 8.42 2.59
44 6.39 2.46 6.76 2.50 7.13 2.53 7.32 2.55 7.50 2.57 7.88 2.61 8.27 2.65
46 6.24 2.51 6.61 2.55 6.98 2.59 7.17 2.61 7.36 2.63 7.74 2.67 8.12 2.71
2500 2500 3500 3500 12000 150%
10 9.00 1.38 9.35 1.41 9.71 1.44 9.89 1.46 10.07 1.47 10.44 1.50 10.81 1.53
12 8.84 1.42 9.19 1.45 9.55 1.48 9.73 1.49 9.92 1.51 10.29 1.54 10.66 1.57
14 8.68 1.46 9.04 1.49 9.40 1.52 9.58 1.53 9.76 1.55 10.13 1.58 10.51 1.61
16 8.53 1.50 8.88 1.53 9.24 1.56 9.43 1.57 9.61 1.59 9.98 1.62 10.36 1.65
18 8.37 1.53 8.73 1.56 9.09 1.59
9.27 1.61 9.46 1.63 9.83 1.66 10.21 1.69
20 8.22 1.57 8.57 1.60 8.94 1.64 9.12 1.65 9.30 1.67 9.68 1.70 10.05 1.73
21 8.14 1.59 8.50 1.62 8.86 1.66 9.04 1.67 9.23 1.69 9.60 1.72 9.98 1.75
23 7.99 1.64 8.34 1.67 8.71 1.70 8.89 1.71 9.08 1.73 9.45 1.76 9.83 1.79
25 7.83 1.68 8.19 1.71 8.56 1.74 8.74 1.75 8.92 1.77 9.30 1.80 9.68 1.83
27 7.68 1.72 8.04 1.75 8.40 1.78 8.59 1.80 8.77 1.81 9.15 1.84 9.53 1.87
29 7.53 1.76 7.89 1.79 8.25 1.82 8.44 1.84 8.62 1.86 9.00 1.89 9.38 1.92
31 7.37 1.81 7.74 1.84 8.10 1.87 8.29 1.88 8.47 1.90 8.85 1.93 9.23 1.96
33 7.22 1.85 7.58 1.88 7.95 1.91 8.14 1.93 8.32 1.94 8.70 1.98 9.08 2.01
35 7. 07 1.89 7.43 1.93 7.80 1.96 8.00 1.97 8.17 1.99 8.55 2.02 8.93 2.05
37 6.92 1.94 7.28 1.97 7.65 2.00 7.84 2.02 8.02 2.04 8.40 2.07 8.79 2.10
39 6.77 1.99 7.13 2.02 7.50 2.05 7. 6 9 2.07 7.87 2.08 8.25 2.12 8.64 2.15
42 6.54 2.06 6.91 2.09 7.28 2.12 7.46 2.14 7.65 2.15 8.03 2.19 8.42 2.22
44 6.39 2.11 6.76 2.14 7.13 2.17 7.32 2.19 7.50 2.20 7.88 2.24 8.27 2.27
46 6.24 2.15 6.61 2.19 6.98 2.22 7.17 2.24 7.36 2.25 7. 74 2.29 8.12 2.32
NOTE
 Cooling capacity is based on 27°CDB / 19°CWB (indoor temperature), 35°CDB (outdoor temperature).
 Heating capacity is based on 20°CDB (indoor temperature), 7°CDB/6°CWB (outdoor temperature).
 The above is the value for connecting with the following indoor units.
- 2000, 2500, 3500, 5000, 6800W class : AR07TXFCAWKNEU, AR09TXFCAWKNEU, AR12TXFCAWKNEU,
AR18TXEAAWKNEU, AR24TXEAAWKNEU
 Capacities are based on the following conditions:
- Corresponding refrigerant piping length : 5m / - Level difference : 0m
 The total ability of connected a indoor unit is up to 12kW
 It is impossible to connect the indoor unit for one room only.
 This data is reference data for temperature capacity trend.
