12. Capacity Table
Combination
(Capacity Index)
Combination
(Total)
Combination
(%)
Outdoor
Temperature
(℃,DB)
Indoor Temperature(℃, DB)
14 16 18 20 21 22 24
TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW) TC(kW) PI(kW)
2500 2500 2500 3500 3500 14500 145%
-15 6.87 2.54 6.65 2.58 6.46 2.62 6.38 2.63 6.30 2.64 6.15 2.67 6.04 2.69
-10 8.23 2.68 8.00 2.72 7.80 2.75 7.70 2.77 7.62 2.78 7.46 2.81 7.33 2.84
-5 9.59 2.81 9.35 2.85 9.13 2.89 9.03 2.91 8.94 2.92 8.77 2.95 8.63 2.98
0 10.95 2.94 10.70 2.98 10.47 3.02 10.37 3.04 10.27 3.06 10.09 3.09 9.93 3.12
2 11.50 2.99 11.24 3.04 11.01 3.08 10.90 3.10 10.80 3.11 10.61 3.15 10.45 3.18
7 12.59 3.10 12.32 3.14 12.08 3.19 12.00 3.20 11.86 3.22 11.67 3.26 11.49 3.29
10 13.69 3.20 13.41 3.25 13.15 3.29 13.04 3.31 12.93 3.33 12.72 3.37 12.54 3.40
15 15.06 3.33 14.77 3.38 14.50 3.42 14.38 3.45 14.26 3.47 14.04 3.50 13.85 3.54
2500 2500 2500 3500 5000 16000 160%
-15 6.87 2.63 6.65 2.67 6.46 2.71 6.38 2.72 6.30 2.74 6.15 2.76 6.04 2.78
-10 8.23 2.77 8.00 2.81 7.80 2.85 7.70 2.86 7.62 2.88 7.46 2.91 7.33 2.93
-5 9.59 2.91 9.35 2.95 9.13 2.99 9.03 3.01 8.94 3.02 8.77 3.05 8.63 3.08
0 10.95 3.04 10.70 3.09 10.47 3.13 10.37 3.15 10.27 3.16 10.09 3.20 9.93 3.23
2 11.50 3.10 11.24 3.14 11.01 3.18 10.90 3.20 10.80 3.22 10.61 3.26 10.45 3.28
7 12.59 3.20 12.32 3.25 12.08 3.29 12.00 3.31 11.86 3.33 11.67 3.37 11.49 3.40
10 13.69 3.31 13.41 3.36 13.15 3.40 13.04 3.43 12.93 3.45 12.72 3.48 12.54 3.52
15 15.06 3.44 14.77 3.49 14.50 3.54 14.38 3.56 14.26 3.58 14.04 3.62 13.85 3.66
2500 2500 3500 3500 3500 15500 155%
-15 6.87 2.58 6.65 2.62 6.46 2.66 6.38 2.67 6.30 2.69 6.15 2.71 6.04 2.73
-10 8.23 2.72 8.00 2.76 7.80 2.80 7.70 2.81 7.62 2.83 7.46 2.86 7.33 2.88
-5 9.59 2.85 9.35 2.90 9.13 2.93 9.03 2.95 8.94 2.97 8.77 3.00 8.63 3.02
0 10.95 2.99 10.70 3.03 10.47 3.07 10.37 3.09 10.27 3.11 10.09 3.14 9.93 3.17
2 11.50 3.04 11.24 3.08 11.01 3.13 10.90 3.15 10.80 3.16 10.61 3.20 10.45 3.23
7 12.59 3.14 12.32 3.19 12.08 3.23 12.00 3.25 11.86 3.27 11.67 3.31 11.49 3.34
10 13.69 3.25 13.41 3.30 13.15 3.34 13.04 3.36 12.93 3.38 12.72 3.42
12.54 3.45
15 15.06 3.38 14.77 3.43 14.50 3.48 14.38 3.50 14.26 3.52 14.04 3.56 13.85 3.59
2500 2500 3500 3500 5000 17000 170%
-15 6.87 2.67 6.65 2.71 6.46 2.75 6.38 2.76 6.30 2.78 6.15 2.80 6.04 2.83
-10 8.23 2.81 8.00 2.85 7.80 2.89 7.70 2.91 7.62 2.92 7.46 2.95 7.33 2.98
-5 9.59 2.95 9.35 2.99 9.13 3.03 9.03 3.05 8.94 3.07 8.77 3.10 8.63 3.13
0 10.95 3.09 10.70 3.13 10.47 3.18 10.37 3.19 10.27 3.21 10.09 3.25 9.93 3.28
2 11.50 3.14 11.24 3.19 11.01 3.23 10.90 3.25 10.80 3.27 10.61 3.30 10.45 3.33
7 12.59 3.25 12.32 3.30 12.08 3.34 12.00 3.36 11.86 3.38 11.67 3.42 11.49 3.45
10 13.69 3.36 13.41 3.41 13.15 3.46 13.04 3.48 12.93 3.50 12.72 3.54 12.54 3.57
15 15.06 3.49 14.77 3.55 14.50 3.60 14.38 3.62 14.26 3.64 14.04 3.68 13.85 3.71
2500 3500 3500 3500 3500 16500 165%
-15 6.87 2.59 6.65 2.63 6.46 2.66 6.38 2.68 6.30 2.69 6.15 2.72 6.04 2.74
-10 8.23 2.73 8.00 2.77 7.80 2.80 7.70 2.82 7.62 2.84 7.46 2.86 7.33 2.89
-5 9.59 2.86 9.35 2.90 9.13 2.94 9.03 2.96 8.94 2.98 8.77 3.01 8.63 3.03
0 10.95 3.00 10.70 3.04 10.47 3.08 10.37 3.10 10.27 3.12 10.09 3.15 9.93 3.18
2 11.50 3.05 11.24 3.09 11.01 3.14 10.90 3.15 10.80 3.17 10.61 3.21 10.45 3.24
7 12.59 3.15 12.32 3.20 12.08 3.24 12.00 3.26 11.86 3.28 11.67 3.32 11.49 3.35
10 13.69 3.26 13.41 3.31 13.15 3.35 13.04 3.37 12.93 3.39 12.72 3.43 12.54 3.46
15 15.06 3.39 14.77 3.44 14.50 3.49 14.38 3.51 14.26 3.53 14.04 3.57 13.85 3.60
NOTE
 Cooling capacity is based on 27°CDB / 19°CWB (indoor temperature), 35°CDB (outdoor temperature).
 Heating capacity is based on 20°CDB (indoor temperature), 7°CDB/6°CWB (outdoor temperature).
 The above is the value for connecting with the following indoor units.
- 2000, 2500, 3500, 5000, 6800W class : AR07TXFCAWKNEU, AR09TXFCAWKNEU, AR12TXFCAWKNEU, AR18TXEAAWKNEU, AR24TXEAAWKNEU
 Capacities are based on the following conditions:
- Corresponding refrigerant piping length : 5m / - Level difference : 0m
 The total ability of connected a indoor unit is up to 17.3kW
 It is impossible to connect the indoor unit for one room only.
 This data is reference data for temperature capacity trend.
